Vishay Single Layer Ceramic Capacitor, 200pF, 20kV DC, N4700 Dielectric, Screw Terminal, 715C20KTT20
Specifications
| Country of Origin | Germany |
|---|---|
| Voltage | 20kV dc |
| Diameter | 21mm |
| Brand | Vishay |
| Height | 23mm |
| Model | 715C20KTT20 |
| Packaging | Bulk |
| Mount Type | Screw |
| Series | 715C |
| Maximum Operating Temperature | 85°C |
| Tolerance | ±20 % |
| Capacitance | 200pF |
| Minimum Operating Temperature | -30°C |
| Terminal type | Screw |
| Dissipation Factor | 0.2% |
| Standards/Approvals | RoHS |
| Package/Case | Disc |
| Pin Count | 2 |
| Dielectric | N4700 |
| Suppression Class | Class I |
Key Features
- High voltage class 1 ceramic disc capacitor for AC and DC applications.
- Capacitance of 200pF, suitable for precision electronic circuits.
- Operates at 20kV DC voltage, ideal for high voltage power supplies.
- ±20% tolerance, ensuring reliable and consistent performance.
- N4700 dielectric for stable temperature characteristics.
- Screw terminal mounting for secure installation.
- Operational temperature range from -30°C to 85°C.
- Disc package with a height of 23mm and diameter of 21mm.
Product Description
Vishay 715C20KTT20 Single Layer Ceramic Capacitor is engineered for demanding high voltage applications, operating at 200pF capacitance and 20kV DC. Featuring an N4700 dielectric, this disc-type capacitor is designed for greater stability under varying temperature conditions, with a tolerance of ±20% for consistent electrical performance. Its screw terminal mounting arrangement provides robust installation, making it suitable for industrial and laboratory environments.
The capacitor’s operational range extends from -30°C up to 85°C, and it is compliant with RoHS, ensuring environmental and regulatory standards are met. The disc package format, with 2-pin screw terminals, combines compact form factor with reliability for circuit integration.
Ideal for use in high voltage power supplies, CO₂ lasers, X-ray and welding equipment, and other industrial electronic circuits requiring dependable performance under extreme voltage and temperature conditions.
Capacitance of 200pF empowers high precision filtering and timing circuits. Rated for 20kV DC voltage, facilitating applications in high voltage environments. Screw type terminals for sturdy mechanical and electrical connection.
N4700 dielectric type delivers thermal and frequency stability. Disc package, 23mm height × 21mm diameter, enables easy PCB or chassis mounting. Class I suppression class ensures safety and regulatory compliance. RoHS approved for eco-friendly electronics manufacturing.
Manufactured in Germany, reflecting premium quality standards. Frequently used across industrial power electronics, laboratories, and scientific systems. Discover more Vishay high-voltage ceramic capacitors and related products at EnvMart for optimal electronic component selection.
Explore more products in our Single Layer Ceramic Capacitors category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has a capacitance value of 200pF, making it suitable for precision electronic circuits.
It is rated for a maximum voltage of 20kV DC, which is ideal for high voltage power supplies and applications.
The capacitor features an N4700 dielectric, which provides stable temperature characteristics and reliable performance.
The disc package has a height of 23mm and a diameter of 21mm, facilitating easy mounting in various applications.
It features screw terminal mounting, providing a secure mechanical and electrical connection for installation.
This unit has a tolerance of ±20%, ensuring consistent electrical performance in applications.
The dissipation factor is 0.2%, indicating low energy loss during operation.
Yes, it is RoHS compliant, meeting environmental and regulatory standards for electronics.
This model has a pin count of 2, suitable for its screw terminal design.
It is manufactured in Germany, reflecting high quality standards in production.
