Wurth Elektronik 373B Series Pluggable Terminal Block 5-Contact 5.08 mm Pitch 1 Row 300V AC 16A 691373500005B
Specifications
| Country of Origin | Taiwan |
|---|---|
| Voltage | 300V ac |
| Brand | Wurth Elektronik |
| Colour | Green |
| Orientation | Straight |
| Current | 16A |
| Length | 25.4mm |
| Model | 691373500005B |
| Depth | 27.1mm |
| Width | 14.9mm |
| Housing Material | Polyamide |
| Series | 373B |
| Number of Rows | 1 |
| Pitch | 5.08mm |
| Number of Contacts | 5 |
| Minimum Wire Size mm² | 0.21mm² |
| Maximum Wire Size mm² | 3.31mm² |
| Minimum Wire Size AWG | 24AWG |
| Maximum Wire Size AWG | 12AWG |
| Wire Connection Method | Cable Entry |
Key Features
- Constructed from green UL94-V0 polyamide (PA66) housing material.
- Supports wire sizes from 24 AWG to 12 AWG (0.21mm² to 3.31mm²).
- Features M2.6 screw terminals with stamping clamp and stainless steel wire guard.
- Straight orientation with cable entry wire connection method.
- Single-row terminal block suitable for industrial electrical and electronic connections.
Product Description
Wurth Elektronik 691373500005B is a pluggable terminal block from the 373B series, featuring 5 contacts with a 5.08 mm pitch arranged in a single row. This terminal block is designed for reliable electrical connections in industrial, electronic component assemblies, and power distribution applications with a voltage rating of 300V AC and current rating of 16A. It is produced with a green polyamide (PA66) housing material, compliant with UL94-V0 flame retardant standards.
The M2.6 screw terminals utilize a stamping clamp mechanism that ensures secure wire retention, accommodating wire sizes ranging from 24 AWG (0.21 mm²) to 12 AWG (3.31 mm²). A stainless steel wire guard and retention latches on the non-wire side enhance durability and stability during use. The terminal's straight orientation and cable entry method simplify installation in various connector configurations.
Compact dimensions of 25.4 mm length, 14.9 mm width, and 27.1 mm depth make it ideal for PCB mounting and modular electrical assemblies. The component is suitable for use in industrial automation, electronic devices, and power connectors where reliable and safe wire termination is required.
Constructed from green UL94-V0 polyamide (PA66) housing material. Supports wire sizes from 24 AWG to 12 AWG (0.21mm² to 3.31mm²). Features M2.6 screw terminals with stamping clamp and stainless steel wire guard. Straight orientation with cable entry wire connection method.
Compact dimensions: Length 25.4 mm, Width 14.9 mm, Depth 27.1 mm. Single-row 5-contact terminal block for versatile electrical connections.
This product originates from Taiwan, Province Of China, ensuring compliance with regional manufacturing standards. It is widely used in power connectors, industrial control systems, and electronic component assemblies.
Browse other Pluggable Terminal Blocks and connectors from Wurth Elektronik on EnvMart for comprehensive solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The terminal block has a voltage rating of 300V AC and a current rating of 16A.
It supports wire sizes ranging from 24 AWG (0.21 mm²) to 12 AWG (3.31 mm²).
This terminal block features a pitch of 5.08 mm and has 5 contacts arranged in a single row.
The housing is constructed from green UL94-V0 polyamide (PA66).
The dimensions are 25.4 mm in length, 14.9 mm in width, and 27.1 mm in depth.
It uses a cable entry wire connection method with M2.6 screw terminals and a stamping clamp mechanism.
This terminal block originates from Taiwan, Province Of China.
It features a stainless steel wire guard and retention latches on the non-wire side for enhanced durability and stability.
The terminal block has a straight orientation for easy installation.
This model belongs to the 373B series of pluggable terminal blocks.
The UL94-V0 rating indicates that the housing material is flame retardant, enhancing safety in electrical applications.
