Weidmüller OMNIMATE SL Series Pluggable Terminal Block, 4-Contact, 5.08 mm Pitch, 1 Row 1838230000
Specifications
| Country of Origin | Germany |
|---|---|
| Voltage | 400V |
| Brand | Weidmüller |
| Colour | Black |
| Orientation | Straight |
| Current | 19A |
| Length | 15.2mm |
| Depth | 8.5mm |
| Width | 22.22mm |
| Housing Material | Glass Filled Liquid Crystal Polymer |
| Series | OMNIMATE SL |
| Number of Rows | 1 |
| Pitch | 5.08mm |
| Standards/Approvals | IEC 60664-1, IEC 61984, RoHS, UL 1059 |
| Pay online using | Or choose to pay later via bank transfer |
| RS Stock No. | 733-0608Brand: WeidmüllerManufacturers Part No.: 1838230000 |
| Number of Contacts | 4 |
| Connector Gender | Male |
| Wire Connection Method | Solder |
Key Features
- The housing is constructed from glass-filled liquid crystal polymer ensuring durability.
- The connector operates at a voltage rating of 400 V and supports current up to 19 A.
- Featuring a straight orientation and black color for easy identification.
- Compliant with IEC 60664-1, IEC 61984, RoHS, and UL 1059 standards for safety and performance.
- Ideal for PCB mounting with a depth of 8.5 mm, length of 15.2 mm, and width of 22.22 mm.
- Designed for use in electrical and electronic industrial systems requiring secure and efficient connections.
- Closed ends with vertical SMT headers support wave or reflow soldering in surface mount technology.
Product Description
Weidmüller 1838230000 OMNIMATE SL Series Pluggable Terminal Block is a premium quality, 4-contact pluggable terminal designed to deliver reliable wire-to-board connectivity in demanding industrial and electronic applications. The terminal features a robust housing made from glass-filled liquid crystal polymer that withstands high temperatures, making it suitable for wave or reflow soldering processes in surface mount technology (SMT).
With a pitch of 5.08 mm and a single-row configuration, this male connector provides a secure solder connection method that supports currents up to 19 A at a voltage rating of 400 V. Its straight orientation and black color facilitate easy integration and identification within control panels, automation systems, and electronic equipment.
The compact dimensions - depth of 8.5 mm, length of 15.2 mm, and width of 22.22 mm - enable efficient use of PCB space while maintaining durability and ease of installation. The terminal block complies with international standards IEC 60664-1, IEC 61984, RoHS directives, and UL 1059 ensuring high performance and safety.
The product is manufactured in Germany, reflecting stringent quality controls and superior craftsmanship. The closed ends and vertical SMT header design allow for flexible mounting options on printed circuit boards, supporting various assembly requirements.
The durable housing material ensures resistance to thermal and mechanical stress. High 19 A current rating supports a wide range of industrial electrical applications. Compatible with wave and reflow soldering for advanced PCB assembly.
Standardized pitch of 5.08 mm aligns with Weidmüller's OMNIMATE range for easy system integration. Meets multiple international electrical and safety standards for reliability.
This Pluggable Terminal Block is ideal for electronic, industrial automation, power distribution, and manufacturing applications requiring secure and efficient electrical connectors. Explore the Weidmüller OMNIMATE SL series for complementary components and system solutions on EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
It operates at a voltage rating of 400 V.
This terminal block supports a maximum current of 19 A.
The dimensions are a depth of 8.5 mm, length of 15.2 mm, and width of 22.22 mm.
The housing is constructed from glass-filled liquid crystal polymer.
It complies with IEC 60664-1, IEC 61984, RoHS, and UL 1059 standards.
This model features 4 contacts.
The connector has a pitch size of 5.08 mm.
It utilizes a solder wire connection method.
The terminal block features a straight orientation.
It is manufactured in Germany.
It is designed for use in electrical and electronic industrial systems requiring secure and efficient connections.
This terminal block has a male connector gender.
