Weidmüller OMNIMATE SC Series Pluggable Terminal Block 4-Contact 3.81mm Pitch 1 Row 320V 17.5A 1793150000
Specifications
| Country of Origin | China |
|---|---|
| Voltage | 320V |
| Brand | Weidmüller |
| Colour | Black |
| Orientation | Right Angle |
| Current | 17.5A |
| Length | 3.2mm |
| Depth | 9.2mm |
| Width | 16.64mm |
| Housing Material | Glass Filled Polyamide |
| Series | OMNIMATE SC |
| Number of Rows | 1 |
| Pitch | 3.81mm |
| Standards/Approvals | CSA, cURus |
| Pay online using | Or choose to pay later via bank transfer |
| RS Stock No. | 739-3766Brand: WeidmüllerManufacturers Part No.: 1793150000 |
| Number of Contacts | 4 |
| Connector Gender | Male |
| Wire Connection Method | Solder |
Key Features
- This pluggable terminal block uses glass-filled polyamide for housing and black color design.
- It supports right angle orientation with solder wire connection method for secure attachment.
- The connector gender is male, suitable for various electronic and electrical applications.
- Compact dimensions include 3.2mm length pin and 16.64mm width with 9.2mm depth for space efficiency.
- Standards and approvals include CSA and cURus ensuring compliance and reliability.
- Ideal for industrial, electronic, and power connector use cases requiring durability and secure connections.
Product Description
Weidmüller 1793150000 OMNIMATE SC Series Pluggable Terminal Block is designed as a reliable 4-contact electronic component with a 3.81 mm pitch and a single row configuration. With a rated voltage of 320V and a continuous current of 17.5A, this terminal block meets rigorous industrial standards including CSA and cURus approvals.
The housing is made from glass-filled polyamide, providing outstanding mechanical strength and thermal stability, while the black color offers a professional electrical component appearance. Featuring a male connector gender and right angle orientation, this terminal block is tailored for secure solder wire connections, ensuring a robust electrical connection in printed circuit board assemblies and other electronic applications.
The compact physical dimensions with a pin length of 3.2 mm, width of 16.64 mm, and depth of 9.2 mm allow for efficient space management in densely packed electrical panels or devices. This product originates from China and is part of the esteemed OMNIMATE SC series by Weidmüller, well known for quality and dependable connectivity solutions.
This terminal block is suitable for industrial automation, manufacturing equipment, control panels, and electronic device assembly. The product complies with stringent certification requirements, assuring user confidence in safety and performance.
The use of glass-filled polyamide enhances durability against mechanical stress and environmental factors. Supports wave soldering processes with 3.2 mm pin length designed for optimal solder joint quality. Right angle pluggable design enables flexible circuit layouts and easy mechanical integration.
Compact size and standardized pitch facilitate compatibility with a wide range of connectors and sockets. Explore more from the OMNIMATE SC series for complementary Pluggable Terminal Blocks and connector solutions tailored to diverse power and signal transmission needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This terminal block has a rated voltage of 320V and a continuous current of 17.5A.
The dimensions of this model are 3.2mm in length, 16.64mm in width, and 9.2mm in depth.
The housing is made from glass-filled polyamide, providing mechanical strength and thermal stability.
The pitch of the contacts is 3.81mm.
This terminal block features 4 contacts.
It has a right angle orientation, which allows for flexible circuit layouts.
This model supports a solder wire connection method for secure attachment.
It complies with CSA and cURus standards, ensuring reliability and safety.
The connector gender is male, suitable for various electronic and electrical applications.
It is suitable for industrial automation, manufacturing equipment, control panels, and electronic device assembly.
This product originates from China.
This terminal block is part of the OMNIMATE SC series by Weidmüller.
