Weidmüller OMNIMATE SL Series Pluggable Terminal Block, 3-Contact, 5.08 mm Pitch, 1 Row 1838220000

Weidmüller 1838220000 OMNIMATE SL Series Pluggable Terminal Block is a precision 3-contact connector designed for electronic applications requiring high reliability and SMT compatibility. The terminal block features a 5.08 mm pitch and a single row configuration, ideal for compact PCB layouts. It is manufactured using glass filled liquid crystal polymer housing material that provides excellent mechanical strength and high temperature resistance, making it suitable for wave or reflow soldering processes.

With a current rating of 19A and voltage capacity up to 400V, this connector supports robust electrical performance. The male gender, straight orientation connector ensures easy integration with mating cable mount terminals available in screw clamp, rising clamp, or tension clamp types. The solder wire connection method enhances secure termination and electrical continuity.

The component dimensions are compact with overall length of 15.2 mm, width of 17.14 mm, and depth of 8.5 mm, accommodating dense assembly requirements. The 3.2 mm pin length is tailored for through-hole reflow (THR) applications, combining the advantages of surface mount technology with reliable through-hole connections.

The OMNIMATE SL Series also includes polarising pins that prevent incorrect connector mating, ensuring installation integrity. This terminal block is suited for industrial, electronic manufacturing, automation systems, and power connector applications needing dependable wire-to-board connections.

Glass filled liquid crystal polymer housing provides high mechanical and thermal performance. Supports current up to 19A and voltage up to 400V for diverse electronic circuits. Male straight orientation allows straightforward integration on PCBs.

Suitable for wave or reflow soldering in SMT manufacturing processes. Compact 3-contact design with a 5.08 mm pitch and single row layout. Polarising pins help prevent mismatch connections on board assembly. Manufactured in Germany, ensuring premium quality and reliability.

This Pluggable Terminal Block is a reliable solution for electronic component assembly in industrial, manufacturing, automation, and power connector applications. Explore the complete Weidmüller OMNIMATE SL Series for compatible mating terminals and advanced wire-to-board connection options at EnvMart.
