Weidmüller BL Series Pluggable Terminal Block 7-Contact 3.5mm Pitch 1 Row 320V 17A 1606690000
Specifications
| Country of Origin | Germany |
|---|---|
| Voltage | 320V |
| Brand | Weidmüller |
| Colour | Orange |
| Orientation | 180° |
| Current | 17A |
| Depth | 18.5mm |
| Width | 31.5mm |
| Housing Material | Polybutylene Terephthalate |
| Series | BL |
| Number of Rows | 1 |
| Pitch | 3.5mm |
| Number of Contacts | 7 |
| Connector Gender | Female |
| Minimum Wire Size mm² | 28mm² |
| Maximum Wire Size mm² | 14mm² |
| Minimum Wire Size AWG | 28AWG |
| Maximum Wire Size AWG | 14AWG |
| Wire Connection Method | Clamping Yoke |
Key Features
- This terminal block uses a clamping yoke screw system for secure wire connection.
- The housing material is durable Polybutylene Terephthalate with an orange color for visibility.
- The product supports wire sizes from 28 AWG to 14 AWG (0.28mm² to 1.4mm²).
- It features a standard density flanged connector cable mount with a 180° orientation.
- The compact size includes a depth of 18.5 mm and a width of 31.5 mm.
- The current-carrying parts are tin-plated copper alloy for reliable conductivity.
- It is manufactured in Germany ensuring high build quality and standards.
Product Description
Weidmüller 1606690000 BL Series Pluggable Terminal Block is engineered as a 7-contact, 3.5 mm pitch, 1-row female connector rated for 320V and 17A, ideal for industrial and electronic applications requiring reliable electrical connections.
The terminal block utilizes a clamping yoke screw system that provides secure and easy wiring, ensuring excellent mechanical and electrical stability. Its housing is made from robust Polybutylene Terephthalate material, colored orange for easy identification and enhanced safety.
This connector supports a wide range of wire sizes from 28 AWG to 14 AWG, accommodating both small and medium gauge wires, and is equipped with two-part terminals featuring tin-plated copper alloy contacts, enhancing corrosion resistance and conductivity.
Dimensionally compact with a depth of 18.5 mm and width of 31.5 mm, the device supports a current rating of 17A and a voltage rating of 320V, suitable for control panels, automation systems, and general PCB applications.
The product is manufactured in Germany, evidencing stringent quality protocols. Its 180° orientation and one-row layout make it versatile for easy installation in confined spaces, complying with industry standards for pluggable terminal blocks.
This terminal block uses a clamping yoke screw system for secure wire connection. The housing material is durable Polybutylene Terephthalate with an orange color for visibility. The product supports wire sizes from 28 AWG to 14 AWG (0.28mm² to 1.4mm²).
It features a standard density flanged connector cable mount with a 180° orientation. The compact size includes a depth of 18.5 mm and a width of 31.5 mm. The current-carrying parts are tin-plated copper alloy for reliable conductivity.
It is manufactured in Germany ensuring high build quality and standards.
This component is ideally suited for applications in industrial equipment, control cabinets, automation, manufacturing, and electronic assembly requiring reliable and standard pitch Pluggable Terminal Blocks.
Explore more under the Electronics & Electricals category for quality Weidmüller connectors and reliable terminal block solutions at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This terminal block is rated for a voltage of 320V and a current of 17A.
It supports wire sizes from 28 AWG to 14 AWG, which corresponds to 0.28mm² to 1.4mm².
The terminal block features a pitch of 3.5mm and includes 7 contacts.
The housing is made from Polybutylene Terephthalate, which is colored orange for visibility.
Wiring is secured using a clamping yoke screw system, ensuring stable connections.
It has a depth of 18.5 mm and a width of 31.5 mm.
This model features a 180° orientation for its flanged connector cable mount.
It is manufactured in Germany, ensuring adherence to high build quality standards.
This terminal block is part of the Weidmüller BL Series.
It is suitable for industrial equipment, control cabinets, automation, manufacturing, and electronic assembly.
This terminal block has a female connector gender.
It is designed for easy installation in confined spaces due to its compact size and 180° orientation.
