DiodesZetex 20 V 200 mW General Purpose Surface Mount Zener Diode SOD-323 BZT52C20S-7-F

Free Delivery in India | Lowest Global Shipping Charges

DiodesZetex 20 V 200 mW General Purpose Surface Mount Zener Diode SOD-323 BZT52C20S-7-F

Name: DiodesZetex 20 V 200 mW General Purpose Surface Mount Zener Diode SOD-323 BZT52C20S-7-F
Brand: DiodesZetex
SKU: 377765
Price: 0.04 USD
Availability: InStock



Category Zener Diode Brand DiodesZetex Condition New

Specifications

Country of Origin	China
Brand	DiodesZetex
Height	1.1mm
Length	2.7mm
Model	BZT52C20S-7-F
Mount Type	Surface
Series	BZT52C20S
Maximum Operating Temperature	150°C
Package Type	SOD-323
Minimum Operating Temperature	-65°C
Pin Count	2
Number of Elements per Chip	1
Automotive Standard	AEC-Q101
Maximum Power Dissipation Pd	200mW
Diode Configuration	Single
Test Current It	5mA
Maximum Reverse Leakage Current	100nA
Nominal Zener Voltage Vz	20V
Zener Type	General Purpose
Maximum Zener Impedance	55Ω
Typical Voltage Temperature Coefficient	14.4mV/°C
Surface Mount case	SOD-323 (SC-76)

Key Features

Capable of dissipating 200 mW power for reliable voltage regulation.
Nominal Zener voltage of 20 V with a voltage tolerance of ±6%.
Designed for surface mount applications with SOD-323 package dimension.
Maximum operating temperature of 150°C and minimum of -65°C for robust performance.
Features low maximum reverse leakage current of 100 nA for efficiency.
Maximum Zener impedance of 55 Ω ensuring voltage stabilization at test current 5 mA.
Compact size with length 2.7 mm and height 1.1 mm, suitable for space-constrained PCBs.
Automotive qualified to AEC-Q101 standard, confirming reliability in automotive applications.

Product Description

DiodesZetex BZT52C20S-7-F is a single element Zener diode intended for voltage regulation and reference applications with nominal voltage of 20 V. It is designed in a compact surface mount SOD-323 package suitable for automated PCB assembly and high-density circuits.

This diode features a maximum power dissipation rating of 200 mW, permitting it to handle moderate power loads efficiently in various electronic circuits. Its maximum operating temperature of 150°C and minimum operating temperature down to -65°C enable it to work reliably in harsh industrial and automotive environments.

The diode has a low maximum reverse leakage current of 100 nA, contributing to energy efficiency and reduced power losses. Its maximum Zener impedance is 55 Ω at a test current of 5 mA, providing stable voltage clamping action.

Measuring only 2.7 mm in length and 1.1 mm in height, it is ideal for space-saving electronic device designs. The product complies with the automotive industry standard AEC-Q101, making it suitable for use in automotive electronic systems requiring high reliability.

The single chip element and general purpose Zener diode type make this product versatile for a broad range of applications including voltage reference, surge suppression, and voltage stabilization in industrial, automotive, telecommunications, and consumer electronics sectors.

Capable of dissipating 200 mW power for reliable voltage regulation. Nominal Zener voltage 20 V with ±6% tolerance ensures precise voltage references. Compact surface mount package SOD-323 fits onto compact PCB layouts. Wide operating temperature range (-65°C to 150°C) enables use in extreme environments.

Low reverse leakage current minimizes power loss and heat generation. Complies with Automotive AEC-Q101 standard for high reliability applications. Compact physical size eases integration into high density PCBs. Single element chip design simplifies circuit implementation.

Suitable for industrial, automotive, telecommunications, and consumer electronics applications.

Ideal for designers seeking a durable and efficient Zener Diode for voltage regulation and protection tasks. Explore other electronic components and semiconductors at EnvMart for complete circuit solutions.
