DiodesZetex 4-Channel Inverting Schmitt Trigger Input 3 State Buffer 14-Pin SOIC 74HC126S14-13

DiodesZetex 74HC126S14-13 is a high-performance 4-channel inverting Schmitt trigger input 3 state buffer housed in a compact 14-pin SOIC package. Designed using advanced CMOS technology, it provides a versatile logic solution suitable for a wide range of industrial, electronic, and embedded applications requiring signal buffering and conditioning.

Operating within a voltage supply range of 2 V to 6 V, this device supports low power consumption with a typical supply current of 40 μA. The integrated Schmitt trigger inputs enhance noise immunity, making it ideal for signal integrity preservation in noisy environments. The 3-state output facilitates multiple bus configurations and enables efficient control of data flow in complex circuits.

Engineered for robustness, it functions reliably across a broad temperature span from -40°C to 125°C. Its maximum propagation delay of 150 ns at specified capacitive load ensures swift switching performance, essential for timing-critical applications.

The device includes negative polarity inverting buffers that can sink or source up to 4 mA at a 4.5 V supply, accommodating diverse electrical interface requirements. Its surface-mount SOIC package supports automated PCB assembly techniques to streamline manufacturing efficiency.

Although it lacks specific automotive certifications, the 74HC126S14-13 meets general industrial standards and RoHS compliance, reflecting responsible manufacturing practices. Four independent inverting Buffers with three-state outputs for complex logic architectures.

Schmitt trigger inputs improve tolerance to noisy input signals and enhance switching reliability. Wide operating temperature range from -40°C to +125°C for use in demanding conditions. Low power dissipation supporting energy-efficient electronic designs.

Compact 14-pin SOIC package suitable for surface mount PCB assembly. Supplies a maximum output current of -4 mA (high level) and 5.2 mA (low level). Typical maximum propagation delay time of 150 ns at load capacitance. Voltage supply operation range from 2 V up to 6 V for flexible integration.

Schmitt trigger inputs for improved noise margins and signal stability. Meets RoHS environmental standards, manufactured in China.

Ideal for applications in general industrial automation, signal processing, and electronic control systems, this buffer IC provides reliable and efficient performance. Explore the DiodesZetex range at EnvMart for other semiconductor components and logic ICs that meet your project requirements.
