DiodesZetex 4-Channel Non-Inverting Schmitt Trigger Input 3 State Buffer, 14-Pin TSSOP 74HC125T14-13

Free Delivery in India | Lowest Global Shipping Charges

DiodesZetex 4-Channel Non-Inverting Schmitt Trigger Input 3 State Buffer, 14-Pin TSSOP 74HC125T14-13

Name: DiodesZetex 4-Channel Non-Inverting Schmitt Trigger Input 3 State Buffer, 14-Pin TSSOP 74HC125T14-13
Brand: DiodesZetex
SKU: 372896
Price: 0.16 USD
Availability: InStock



Category Buffers Brand DiodesZetex Condition New

Specifications

Country of Origin	China
Brand	DiodesZetex
Height	1.05mm
Length	5.1mm
Model	74HC125T14-13
Mount Type	Surface
Output type	3 State
Supply Voltage range	2 V to 6 V
Series	74HC125
Input Type	Schmitt Trigger
Maximum Operating Temperature	125°C
Package Type	TSSOP
Minimum Operating Temperature	-40°C
Polarity	Non-Inverting
Number Of Channels	4
Pin Count	14
Maximum Supply Voltage	6V
Logic Family	HC
Logic Function	Schmitt Trigger Buffer
Minimum Supply Voltage	2V
Maximum High Level Output Current	-4mA
Maximum Propagation Delay Time @ CL	150ns
Supply Current	40μA
Maximum Low Level Output Current	5.2mA
Sinks or Sources 4 mA at VCC	4.5 V

Key Features

Operates with a supply voltage range from 2 V to 6 V.
Features 4 non-inverting channels with Schmitt trigger inputs for signal conditioning.
Surface mount package type ideal for compact PCB layouts.
Maximum propagation delay time of 150 ns at load capacitance.
Designed for operating temperatures from -40°C to 125°C.
Low supply current of 40 µA ensures energy-efficient operation.
Pin count of 14 for easy integration in various electronic systems.
Outputs support three-state logic with maximum high-level output current of -4 mA and low-level of 5.2 mA.

Product Description

DiodesZetex 74HC125T14-13 is a 4-channel non-inverting Schmitt trigger input buffer housed in a 14-pin Thin Shrink Small Outline Package (TSSOP). Designed for low power CMOS technology, this buffer IC is ideal for various logic applications requiring clean signal conditioning with hysteresis.

The device operates reliably over a broad supply voltage range of 2 V to 6 V and maintains low quiescent current consumption of 40 μA, making it suitable for battery-powered and low-power industrial devices. Its high noise immunity is achieved through Schmitt trigger inputs that convert slow or noisy signals into clean digital outputs.

This IC features three-state outputs allowing multiple devices to share output lines without interference. The propagation delay time is typically 150 nanoseconds at standard load conditions, supporting efficient data processing speeds in embedded and digital systems.

With operational temperature limits from -40°C to 125°C and ESD protection exceeding industry standards, the 74HC125T14-13 buffer is well-suited for use in industrial automation, communication equipment, and consumer electronics.

Typical applications include digital buffers, line drivers, and interfacing circuits in automotive electronics, instrumentation, and control systems. The compact 14-pin TSSOP package aids in space-constrained PCB designs.

Operates at supply voltage range of 2 V to 6 V. Four non-inverting Schmitt trigger input channels ensure signal stability. Three-state outputs facilitate bus-oriented applications. Low supply current of 40 μA enhances energy efficiency.

Wide operating temperature range supports industrial use cases. Robust ESD protection exceeds multiple standards. Compact 14-pin TSSOP package optimizes space on circuit boards. Maximum propagation delay time of 150 ns for fast switching.

Manufactured in China under controlled quality processes. Explore the comprehensive range of semiconductor Buffers and logic ICs available at EnvMart for your industrial and electronics manufacturing needs.
