onsemi Zener Diode 24 V 1.5 W Voltage Regulator Surface Mount DO-214AC 2-Pin 1SMA5934BT3G

The onsemi 1SMA5934BT3G is a single-element Zener diode designed for precise voltage regulation at a nominal voltage of 24 V. This surface mount device is enclosed in a DO-214AC package with 2 pins, making it ideal for compact electronic circuits where space-saving is critical. With a maximum power dissipation of 1.5 W, it provides reliable voltage clamping in various power and signal conditioning applications.

Designed to operate efficiently from -65°C to 150°C, this Zener diode sustains stable performance across a wide temperature range, suitable for automotive and industrial environments. Its 5% tolerance on voltage ensures precision in voltage regulation, which is essential in protecting sensitive components in electronic assemblies.

The device features a nominal test current of 15.6 mA, maximum zener impedance of 19 Ω, and a negligible reverse leakage current of 500 nA, all contributing to reliable and efficient circuit operation. Compliance with RoHS directives and AEC-Q101 automotive standards confirms its suitability for use in stringent quality-controlled applications.

This Zener Diode is particularly useful in power supplies, voltage regulation circuits, and transient voltage suppression roles, especially in automotive electronics, industrial electronics, and semiconductor designs requiring robust and compliant components.

The diode features a 5% voltage tolerance for reliable performance. Its surface mount DO-214AC package ensures compact installation in modern electronics. It has a maximum power dissipation of 1.5 Watts suitable for moderate power circuits.

The device operates within a temperature range of -65°C to 150°C, providing robust environmental stability. It exhibits low maximum reverse leakage current of 500 nA maintaining energy efficiency. Its nominal test current is 15.6 mA with a maximum zener impedance of 19 Ω.

The diode complies with RoHS and automotive standard AEC-Q101, ensuring environmental and quality standards. Compact physical dimensions include length of 5.59 mm and height of 2.2 mm allowing space-saving design. Single element per chip configuration assures dedicated voltage regulation performance.

Suitable for industrial, automotive, and electronic manufacturing sectors, this diode enhances system protection and voltage stability in demanding applications. Explore more high-quality onsemi semiconductors in EnvMart’s extensive catalog for precise electronic component solutions.
