Wurth Elektronik WE-MAPI 2510 Wirewound Surface Mount Inductor with Composite Iron Powder Core 1 μH ±20 % 2.5A 74438323010

Wurth Elektronik 74438323010 is a WE-MAPI series wirewound surface mount power inductor featuring a composite iron powder core, providing excellent magnetic properties for high current handling and low noise operation. This inductor comes in a 2510 package size, measuring 2.5mm in length, 2mm in depth, and 1mm in height, making it suitable for space-constrained PCB designs.

The 1 μH inductance with a tolerance of ±20 % allows flexible use in various DC/DC converter and power supply applications. It supports a maximum DC current of 2.5A and has a low maximum DC resistance of 75mΩ, which ensures energy efficiency by reducing losses during operation. The device is moulded for durability and comes with surface mount terminations, facilitating automated manufacturing processes.

Designed to meet automotive standard AEC-Q200, this inductor performs reliably within an operating temperature range from -40°C to 125°C, ensuring stable operation in harsh environments. The maximum self-resonant frequency of 80MHz allows use in high-frequency circuits and switching power supplies.

Typical applications for the WE-MAPI series include DC/DC converters for high current power supplies, field programmable gate arrays (FPGA), POL converters, and portable devices such as PDAs and digital cameras. It also suits mainboards, graphic cards, battery-powered devices, wireless communication devices, and power supplies for smartphones and tablets.

The component is packaged in tape & reel form, supporting efficient placement and assembly in high-volume manufacturing. Manufactured in Korea, Republic Of, this quality inductor combines performance, durability, and compact design for diverse industrial and electronic manufacturing needs.

Composite iron powder core provides high magnetic saturation. Maximum DC current rating of 2.5A suitable for power electronics. Moulded construction ensures robust mechanical strength. Wide operating temperature from -40°C to 125°C supports harsh environments.

Low DC resistance of 75mΩ minimizes power losses. Maximum self-resonant frequency up to 80MHz for high frequency performance. Automotive standard AEC-Q200 qualified for reliable automotive usage. Termination style is surface mount for automated PCB assembly.

Packaging in tape & reel format for manufacturing efficiency. Compact dimensions: 2.5mm length x 2mm depth x 1mm height. Explore more Wurth Elektronik inductors and related surface mount components on EnvMart for comprehensive industrial electronic applications.
