STMicroelectronics High Voltage PNP Transistor -500 mA, -500 V, 3-Pin Surface Mount SOT-23 STR2550

STMicroelectronics STR2550 is a high voltage, PNP bipolar transistor designed for surface mount technology (SMT) applications. It offers a maximum DC collector current of -500 mA and a maximum collector-emitter voltage of -500 V, making it suitable for a variety of industrial, electronic, and power control circuits.

This transistor features a compact 3-pin SOT-23 package, allowing for efficient PCB layout and space optimization in electronic assemblies. With a minimum DC current gain (hFE) of 10 and a power dissipation rating of 500 mW, it ensures reliable switching and amplification performance in low to medium power applications.

The STR2550 is rated for a maximum operating temperature of 150°C, supporting durability and stability in demanding thermal environments. It is configured as a single PNP transistor with a maximum collector-base voltage and emitter-base voltage of -500 V and -7 V respectively.

Its physical dimensions - length 3.04 mm, width 3 mm, height 1.4 mm - facilitate compact designs and integration into automated manufacturing processes. This transistor does not adhere to automotive standards but is well-suited for applications in industrial electronics, power management, and semiconductor circuit designs.

High voltage PNP transistor for surface mount use. Maximum collector current of -500 mA rated for power control applications. Collector-emitter voltage up to -500 V suitable for high voltage applications. Compact SOT-23 3-pin package for efficient PCB mounting.

Minimum DC current gain (hFE) of 10 for stable amplification. Rated 500 mW power dissipation to handle medium power levels. Wide operating temperature tolerance up to 150°C for harsh environments. Single transistor configuration simplifies circuit design.

Precise dimensions to fit small form factor electronic devices. Explore other Bipolar Transistors and semiconductor products at EnvMart for your electronic component needs.
