| Country of Origin | India |
|---|---|
| Brand | onsemi |
| Height | 1.25mm |
| Length | 2.84mm |
| Model | MMSD301T1G |
| Width | 1.8mm |
| Mount Type | Surface |
| Maximum Operating Temperature | 125°C |
| Package Type | SOD-123 |
| Minimum Operating Temperature | -55°C |
| Standards/Approvals | Pb-Free, RoHS |
| Pin Count | 2 |
| Automotive Standard | AEC |
| Maximum Continuous Forward Current If | 200mA |
| Peak Reverse Repetitive Voltage Vrrm | 30V |
| Diode Configuration | Single |
| Rectifier Type | Schottky |
| Peak Reverse Current Ir | 200nA |
| Maximum Forward Voltage Vf | 600mV |
| onsemi 60V 2A, Schottky Diode, 2-Pin SOD-123FL NTS260SFGBrand | onsemi |
onsemi MMSD301T1G is a Schottky Barrier Diode in a compact 2-Pin SOD-123 surface mount package suitable for low voltage, high-frequency rectification and polarity protection applications in electronic circuits.
This diode employs the Schottky barrier principle using a barrier metal to achieve an optimal forward voltage drop and reverse current trade-off, enhancing efficiency and performance in automotive and industrial environments.
Designed to operate reliably within a wide temperature range of -55°C to 125°C, this device is epoxy moulded and Pb-Free, ensuring compliance with environmental standards and suitability for automated board assembly.
The diode’s package dimensions are 2.84mm length, 1.8mm width, and 1.25mm height, resulting in a lightweight 11.7 mg device that saves PCB space while maintaining mechanical strength and stress protection.
With a maximum continuous forward current of 200 mA, peak reverse voltage of 30 V, and a low forward voltage drop of 600 mV, MMSD301T1G fits a wide range of applications including automotive electronics, power supplies, and signal rectification.
The product adheres to the AEC-Q101 automotive standard, affirming its reliability in harsh environments and use cases requiring automotive quality and performance. Compact 2-Pin SOD-123 surface mount package optimized for space-saving designs.
High efficiency Schottky barrier diode with low forward voltage drop. Wide operating temperature makes it suitable for various automotive and industrial settings. Lead-free and RoHS-compliant materials support eco-friendly manufacturing.
Automotive grade with stress protection and reliable electrical characteristics. Applications include polarity protection, freewheeling diode, and high-frequency rectification. Ideal for use in automotive systems, industrial controls, and consumer electronics.
Explore more on high-performance Schottky Diodes in the Electronics & Electricals category at EnvMart for reliable semiconductor components from top manufacturers like onsemi.
