Wurth Elektronik WE-PD Shielded Wirewound Surface Mount Inductor 22 μH ±20% 1.41 A IDC 7447779122
Specifications
| Country of Origin | China |
|---|---|
| Brand | Wurth Elektronik |
| Height | 4.5mm |
| Length | 7.3mm |
| Depth | 7.3mm |
| Packaging | Tape & Reel |
| Series | WE-PD |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -40°C |
| Inductance | 22μH |
| Standards/Approvals | RoHS |
| Maximum DC Current | 1.41A |
| Maximum DC Resistance | 110mΩ |
| Inductance Tolerance | ±20 % |
| Termination Style | Surface Mount |
| Maximum Self Resonant Frequency | 15MHz |
| Inductor Construction | Wirewound |
| Automotive Standard | AEC-Q200 |
| Recommended solder profile | Reflow |
Key Features
- Magnetically shielded design minimizes leakage field.
- Suitable for switching regulators with low operating voltages and high efficiency.
- Constructed with wirewound technology and moulded plastic base.
- Operating temperature range from -40°C to 125°C ensures reliability.
- Compliant with automotive standard AEC-Q200 and RoHS regulations.
- Maximum DC resistance of 110 mΩ ensures low power loss.
- Recommended reflow solder profile for surface mount technology.
- Maximum self-resonant frequency of 15 MHz for stable performance.
Product Description
Wurth Elektronik 7447779122 shielded wirewound surface mount inductor with 22 μH inductance and ±20% tolerance is designed for industrial and commercial electronics applications requiring power inductors with high efficiency and low losses. This inductor supports a maximum DC current of 1.41 A and features a magnetically shielded construction to reduce interference and leakage fields.
The component is moulded on a plastic base (model series WE-PD) ensuring mechanical robustness and reliable performance. It operates reliably within a temperature range from -40°C to 125°C, making it suitable for demanding automotive and industrial environments. The product complies with AEC-Q200 automotive quality standards and RoHS directives ensuring environment-friendly manufacturing processes.
This inductor comes packaged in tape and reel format, facilitating automated assembly on printed circuit boards using a recommended reflow solder process. Its compact form factor measures 7.3 mm in length and depth, with a height of 4.5 mm, allowing efficient space utilization in densely packed electronic designs.
Magnetically shielded design minimizes leakage field. Suitable for switching regulators with low operating voltages and high efficiency. Wirewound construction with moulded plastic base for durability. Wide operating temperature range from -40°C to 125°C.
Automotive grade compliant with AEC-Q200. Max DC resistance of 110 mΩ reduces power loss. Ideal for integrated DC/DC converters and graphic cards. Maximum self-resonant frequency of 15 MHz ensures stable operation. Tap and reel packaging supports efficient manufacturing.
This surface mount inductor is widely used in industrial, automotive, electronic manufacturing, and power management applications requiring compact and efficient inductors. Its design supports switching regulators, DC/DC converters, and graphic card power circuits where performance and reliability are critical.
