Wurth Elektronik WE-PD Shielded Wirewound Surface Mount Inductor 8.2 μH ±20% 6.25 A Idc 744771008

Free Delivery in India | Lowest Global Shipping Charges

Wurth Elektronik WE-PD Shielded Wirewound Surface Mount Inductor 8.2 μH ±20% 6.25 A Idc 744771008

Name: Wurth Elektronik WE-PD Shielded Wirewound Surface Mount Inductor 8.2 μH ±20% 6.25 A Idc 744771008
Brand: Wurth Elektronik
SKU: 370908
Price: 2.26 USD
Availability: InStock



Category Surface Mount Inductor Brand Wurth Elektronik Condition New

Specifications

Country of Origin	India
Brand	Wurth Elektronik
Height	6mm
Length	12mm
Depth	12mm
Packaging	Tape & Reel
Series	WE-PD
Maximum Operating Temperature	125°C
Minimum Operating Temperature	-40°C
Inductance	8.2μH
Standards/Approvals	IPC/JEDEC J-STD-020D
Maximum DC Current	6.25A
Maximum DC Resistance	20mΩ
Inductance Tolerance	±20 %
Termination Style	Surface Mount
Maximum Self Resonant Frequency	25MHz
Inductor Construction	Wirewound
Automotive Standard	AEC-Q200
Recommended solder profile	Reflow

Key Features

Magnetically shielded design reduces leakage flux and electromagnetic interference.
Optimized for high current handling with low DC resistance of 20 mΩ.
Compact dimensions of 12 mm length, 12 mm depth, and 6 mm height.
Automotive standard compliant (AEC-Q200) ensuring reliable operation from -40°C to 125°C.
Surface mount termination style suitable for automated PCB assembly.
Maximum self-resonant frequency of 25 MHz improves high-frequency performance.
Wirewound inductor construction offers high storage capacity and low self-losses.
Packaged on tape and reel for efficient production line insertion.

Product Description

Wurth Elektronik 744771008 is a magnetically shielded wirewound surface mount inductor designed for power applications requiring high current capacity and low losses. With an inductance of 8.2 μH and a tolerance of ±20%, it caters to integrated DC/DC converters and switching regulators operating efficiently at low voltages.

The inductor features a maximum DC current rating of 6.25 A and a maximum DC resistance of just 20 mΩ, enabling high current loading with minimal power dissipation. Its compact size (12 mm length, 12 mm depth, and 6 mm height) combined with surface mount termination style supports automated assembly and compact PCB designs.

Certified to the automotive AEC-Q200 standard, this inductor reliably operates in extreme temperature ranges from -40°C to 125°C. The recommended solder profile is reflow, making it suitable for modern manufacturing processes.

The magnetically shielded construction significantly reduces leakage flux, enhancing electromagnetic compatibility in dense electronic circuits. It achieves a maximum self-resonant frequency of 25 MHz, suitable for high-frequency switching applications.

Packaged on tape and reel, it facilitates efficient insertion into production lines and assembly machines. Typical industrial uses include switching regulators with greater than 86% efficiency, integrated DC/DC converters, and graphic card power supply circuits.

Magnetically shielded wirewound design minimizes electromagnetic interference. High current capacity with low DC resistance for efficient power delivery. Supports automated surface mount assembly with tape and reel packaging.

Reliable operation within automotive temperature standards and specifications. Compact dimensions suitable for space-constrained PCB layouts. Optimal for switching regulators and efficient power conversion modules. Conforms to IPC/JEDEC J-STD-020D standards for quality assurance.

Offers high self-resonant frequency for superior high-frequency performance. Designed for industrial, automotive, and computing applications. Explore more Surface Mount Inductors and power inductors in the Electronics & Electricals category on EnvMart for your production and design needs.
