onsemi 1 Surface Mount CMOS Shift Register TSSOP 16-Pin MC74HC595ADTR2G

onsemi MC74HC595ADTR2G is a high-speed CMOS shift register designed for use in logic circuits requiring serial-to-parallel or parallel-to-serial data conversion. Housed in a 16-pin TSSOP surface mount package, this device offers a compact form factor suitable for dense circuit designs.

Operating within a voltage range of 2 to 6 volts and capable of functioning up to 125°C, the MC74HC595ADTR2G provides reliable performance in both commercial and automotive applications. The device features positive edge triggering to ensure precise timing control and seamless data handling.

This shift register complies with the AEC-Q100 automotive standard, indicating suitability for use in automotive electronic systems requiring high reliability. Its CMOS input and output compatibility simplify integration with other CMOS logic devices.

The package dimensions are 5.1 mm in length, 4.5 mm in width, and 1.2 mm in height, allowing for efficient use of PCB space. It is ideal for industrial, automotive, and consumer electronics designs where efficient data control and signal processing are necessary.

Operates at 2 to 6 V supply voltage range. Positive edge trigger for clock input ensuring accurate data shifting. Compact TSSOP 16-pin surface mount package. Maximum operating temperature of 125°C for durability in harsh conditions.

Compatibility with CMOS input and output logic levels. Meets AEC-Q100 standard for automotive applications. Physical dimensions: 5.1x4.5x1.2 mm (LxWxH).

This product is part of the 74HC family by onsemi, offering high-speed CMOS logic components for various electronic applications including counter circuits, signal processing, and digital interfacing.
