Samtec SLW Series Straight Through Hole PCB Socket 100-Contact 2 Row 2.54 mm Pitch 7.1 A Current 550 V Voltage SLW-150-01-G-D

Free Delivery in India | Lowest Global Shipping Charges

Samtec SLW Series Straight Through Hole PCB Socket 100-Contact 2 Row 2.54 mm Pitch 7.1 A Current 550 V Voltage SLW-150-01-G-D

Name: Samtec SLW Series Straight Through Hole PCB Socket 100-Contact 2 Row 2.54 mm Pitch 7.1 A Current 550 V Voltage SLW-150-01-G-D
Brand: Samtec
SKU: 366813
Price: 17.87 USD
Availability: InStock



Category PCB Socket Brand Samtec Condition New

Specifications

Country of Origin	India
Voltage	550V
Brand	Samtec
Orientation	Straight
Current	7.1A
Model	SLW-150-01-G-D
Mount Type	Through Hole
Housing Material	Polyester
Contact Material	Bronze
Series	SLW
Termination Type	Solder
Maximum Operating Temperature	125°C
Sub Type	Board-to-Board
Minimum Operating Temperature	-55°C
Number of Rows	2
Pitch	2.54mm
Contact Plating	Gold
Number of Contacts	100
Contact Gender	Female
Connector System	Board-to-Board
Stacking Height	10mm
TLW series low profile square post headers	see stock number 765-6114 typically
TSM series square post headers	see stock number 765-6423 typically
TSW series square post headers	see stock number 767-0820 typically

Key Features

Low profile design with 10 mm stacking height for compact board-to-board interfacing.
Constructed with black glass filled polyester housing for durability and stability.
Tuning fork style contacts made from phosphor bronze with 0.51 μm gold plating for reliable conductivity.
Operates efficiently within a temperature range of -55°C to +125°C.
Square post headers compatible with TLW, TSM, and TSW series headers for flexible integration.
Solder termination type for secure mounting on PCB.
Supports 2.54 mm pitch and two rows of 100 female contacts ensuring high connection density.
Rated for 7.1 A current and 550 V voltage for robust electrical performance.

Product Description

Samtec SLW-150-01-G-D is a straight through hole PCB socket from the SLW Series, designed for board-to-board connections with 100 female contacts arranged in two rows and a 2.54 mm pitch. This connector offers a low profile stacking height of 10 mm, making it ideal for compact electronic assemblies.

The connector housing is constructed from black glass filled polyester, providing excellent durability and insulation. The contacts are made from phosphor bronze and feature a 0.51 μm gold plating on the contact surface and a gold flash on the rest, ensuring superior conductivity and corrosion resistance.

Its solder termination type and through hole mount method allow strong mechanical and electrical connections to printed circuit boards. The temperature range supported is from -55°C to +125°C, supporting reliable usage in harsh and varying environmental conditions.

This socket is rated for 7.1 A current and 550 V voltage, suitable for demanding electronic applications in industrial, manufacturing, and power systems. The connector is compatible with TLW, TSM, and TSW series low profile square post headers, enabling flexible and modular board-to-board configurations.

Low profile design with 10 mm stacking height for space saving. Durable black glass filled polyester housing. Gold plated phosphor bronze contacts for reliable electrical connection. Wide operating temperature range from -55°C to 125°C.

Solder termination for secure PCB mounting. Suitable for 7.1 A current and 550 V voltage applications. Two rows and 100 contacts provide high-density connectivity. Compatible with multiple series of low profile square post headers.

This PCB Socket is ideal for use in industrial electronics, power connectors, telecommunications, and other electronic equipment requiring reliable board-to-board connections. Explore more connectors and related components in the Electronics & Electricals category at EnvMart.

Looking to purchase in bulk?

Purchase item in bulk quantity
Get best price for your business

Comments (0)

No customer reviews for the moment.

Frequently Asked Questions

This model is rated for a current of 7.1 A and a voltage of 550 V, making it suitable for demanding electronic applications.

The stacking height of this PCB socket is 10 mm, which allows for compact board-to-board interfacing.

The housing is made from black glass filled polyester, while the contacts are constructed from phosphor bronze with gold plating for reliable conductivity.

It operates efficiently within a temperature range of -55°C to +125°C, suitable for various environmental conditions.

This socket features 100 female contacts arranged in two rows, ensuring high connection density.

It uses a solder termination type, which provides a secure mounting on printed circuit boards.

This model is compatible with TLW, TSM, and TSW series low profile square post headers for flexible integration.

The contacts are arranged with a pitch of 2.54 mm, which is standard for many electronic applications.

The orientation of this socket is straight, designed for direct board-to-board connections.

The country of origin for this PCB socket is India.

This model features female contacts, suitable for connecting to male headers.

It belongs to the board-to-board connector system, designed for direct connections between PCBs.
