Samtec Straight Through Hole PCB Socket 30-Contact 2 Row 1.27 mm Pitch Solder Mount SFM-115-01-L-D

The Samtec SFM-115-01-L-D is a high-quality straight through hole PCB socket tailored for industrial and manufacturing electronic assembly applications. This 30-contact, dual-row socket maintains a precise 1.27 mm pitch with solder termination suitable for robust board-to-board and cable connections.

Its housing is crafted from liquid crystal polymer, ensuring excellent insulation and mechanical stability in demanding environmental conditions. The contacts are made from beryllium copper alloy, plated with 0.25 microns of gold, providing corrosion resistance and maintaining electrical conductivity over long periods.

With a current rating of 12A and voltage capacity up to 350V, it supports demanding power requirements in industrial electronics. The device operates reliably between -55°C and 125°C, making it suited for harsh operating environments.

The 12 mm stacking height of the socket facilitates efficient board-to-board system designs, simplifying maintenance and upgrading of connected systems.

This product does not hold specific certifications but meets industry norms within the Samtec SFM series for through hole sockets used in electronics manufacturing, laboratory setups, and commercial equipment.

The Samtec SFM-115-01-L-D is typically supplied in tubes for batch insertion into machinery, enhancing production efficiency and ensuring consistent quality in assembly lines. This PCB socket supports a current rating of 12A for reliable electrical performance.

Constructed with a liquid crystal polymer housing for enhanced durability and insulation. The contact material is beryllium copper alloy with 0.25 μm gold plating for corrosion resistance and longevity. Designed with through hole mount type and straight orientation, suitable for board-to-board and cable connector systems.

Operating voltage is rated up to 350V with operating temperatures spanning from -55°C to 125°C. Stacking height of the socket is 12 mm, facilitating proper board-to-board connectivity. The socket is compliant with the SFM series and has no specific standards or approvals.

Application suitable for industrial electronics, power connectors, and PCB assembly in manufacturing and repair fields. Explore more reliable PCB Sockets and connectors in the Electronics & Electricals category on EnvMart for your industrial and commercial needs.
