DiodesZetex 1 2-Input OR Logic Gate, Surface Mount, 5-Pin SOT-353, CMOS, Operating Voltage 1.65 to 5.5 V 74LVC1G32SE-7

DiodesZetex 74LVC1G32SE-7 is a single 2-input OR logic gate integrated circuit featuring low-voltage CMOS technology, designed for high-performance electronic systems. It operates reliably within a supply voltage range of 1.65 to 5.5 volts, making it suitable for a variety of low-power applications and modern digital circuitry where power efficiency is critical.

The device is housed in a compact 5-Pin SOT-353 surface mount package, which minimizes PCB footprint while facilitating automated assembly processes. With a maximum propagation delay of 5.5 nanoseconds, it is optimized for fast switching speeds required in timing-sensitive applications such as data processing, signal routing, and logic control in both industrial and commercial electronics.

This OR gate offers compatibility with LVTTL and TTL input logic levels, while its output follows LVCMOS standards, enabling easy integration with other devices and microcontrollers. The push-pull output stage ensures robust driving capability for subsequent circuit elements without signal degradation.

Designed to endure temperatures from -40°C up to 125°C, the 74LVC1G32SE-7 is apt for use in harsh environments, including industrial automation, instrumentation, and embedded systems. The device does not carry specific automotive approvals but conforms to stringent semiconductor manufacturing quality protocols.

Typical applications include digital logic boards, signal multiplexing, logic function implementation, and embedded control systems in manufacturing and laboratory equipment. Its minimal height of 1 mm and length of 2.2 mm allow for dense multi-layer PCB designs without compromising thermal dissipation.

This integrated OR gate features a single 2-input logic element built on low-voltage CMOS technology. Supports input voltage range from 1.65 V to 5.5 V for broad power supply compatibility. Surface mount 5-Pin SOT-353 package reduces board space and favors automated assembly.

High-speed operation with propagation delay time of 5.5 nanoseconds at typical load. Compatible with standard TTL/LVTTL input and LVCMOS output logic levels. Wide operating temperature range from -40°C to 125°C for industrial-grade applications.

Push-pull output stage enhances output drive capability and signal integrity. Compact device height of 1 mm and length of 2.2 mm supports dense PCB configurations.

Select the DiodesZetex 74LVC1G32SE-7 for efficient, low-power logic gate needs in laboratory, industrial, and commercial electronic designs. Explore more semiconductor and Logic Gate devices within EnvMart's Electronics & Electricals category to fulfill diverse design requirements.
