DiodesZetex 1 2-Input OR Logic Gate, CMOS, Push Pull Output, 5-Pin SOT-25, 1.65 to 5.5 V Operating Voltage 74LVC1G32W5-7

DiodesZetex 74LVC1G32W5-7 is a 1 2-Input OR Logic Gate integrated circuit designed with CMOS technology. It features a surface mount 5-pin SOT-25 package, ideal for compact and efficient PCB assembly. This device operates at a voltage range from 1.65 to 5.5 volts, making it compatible with low-voltage digital systems commonly used in industrial and electronic applications.

The logic gate includes a push pull output stage capable of delivering a maximum output current of ±32 mA, ensuring strong drive capability for subsequent circuitry. Its maximum propagation delay time of 5.5 ns allows fast switching performance, suitable for timing-critical digital logic functions.

Operating temperature ranges from -40°C to 125°C, supporting use in harsh environmental conditions often found in industrial, automotive, and commercial electronics. The device has no Schmitt trigger inputs, meaning it is designed for stable digital signals without the need for noise filtering.

With a compact height of 1.3 mm and length of 3.1 mm, the 5-pin SOT-25 package provides an efficient footprint for surface mount assembly on printed circuit boards, facilitating high-density designs.

DiodesZetex 74LVC1G32W5-7 is part of the 74LVC1G family by Diodes Inc, known for reliable, low-voltage CMOS logic ICs widely used in industrial automation, consumer electronics, and embedded systems requiring robust logic gating functionality.

Single 2-input OR gate with CMOS inputs ensures flexible logic compatibility. Surface mount 5-pin SOT-25 package enables compact board layouts. Supports operating voltages from 1.65 V to 5.5 V for low power consumption. Fast maximum propagation delay of 5.5 nanoseconds enables high-speed switching.

Wide temperature range from -40°C to 125°C supports harsh environments. Push pull output stage delivers symmetrical high and low level currents of 32 mA. No Schmitt trigger input; designed for clean digital signals. Manufactured in China with DiodesZetex quality standards.

For industrial, laboratory, embedded system, consumer electronic, and automation applications requiring efficient Logic Gates with low-voltage CMOS technology, this logic IC offers reliable performance in a space-saving surface mount format. Explore more semiconductor components and logic ICs from DiodesZetex to complete your electronic designs with robust, quality products.
