HARWIN Datamate J-Tek Series Straight Through Hole PCB Header, 12 Contacts, 2 mm Pitch, 2 Row, Shrouded M80-5001242

HARWIN M80-5001242 Datamate J-Tek Series Straight Through Hole PCB Header is a precision connector designed for industrial, military, aerospace, and commercial applications where reliability under harsh conditions is critical. This PCB header features 12 contacts arranged in 2 rows with a 2 mm pitch, providing a robust connection system for complex circuitry.

The housing material is polyphenylene sulphide, which offers excellent thermal stability and chemical resistance. The shrouded design protects the contacts from damage and prevents misalignment during mating.

Its contacts are fabricated from phosphor bronze and plated with gold to ensure high conductivity and corrosion resistance. The connector is rated for a current of 3A and voltage of 120V, suitable for a wide range of electronic equipment operating in demanding environments.

Operating temperatures range from -55°C to 125°C, allowing performance in extreme temperature scenarios. The 3 mm tail pin length facilitates reliable soldering and mechanical stability on PCBs.

Harwin’s Datamate J-Tek connectors are well known for their high mating cycles and resistance to vibration and shock, meeting standards such as BS9525-F0033/MIL C 55302/CEC 75101-008. This ensures dependable electrical performance in high-stress environments including industrial machinery, aerospace controls, and military electronics.

The connector supports board-to-board and wire-to-board configurations, offering design flexibility. The shrouded, straight orientation aids in error-free connection and durability. The housing and contacts are designed specifically for COTS (commercial off-the-shelf) applications.

Harwin’s four-finger beryllium copper contact technology ensures high reliability and long service life. Ideal for applications where safety, vibration resistance, and reliability are essential.

This product is manufactured in the United Kingdom and comes new, ready for integration into electronic assemblies. Explore the full range of HARWIN PCB Headers on EnvMart for compatible components and accessories to complement your design.
