Crydom ED Series Solid State Relay 3 A Load DIN Rail Mount 280 Vrms Load 15V DC Control ED24D3R
Specifications
| Country of Origin | Mexico |
|---|---|
| Brand | Crydom |
| Height | 37.4mm |
| Length | 29mm |
| Model | ED24D3R |
| Width | 12.7mm |
| Mount Type | DIN Rail |
| Output type | AC |
| Series | ED |
| Maximum Operating Temperature | 80°C |
| Contact Configuration | SPST |
| Capacitance | 10pF |
| Minimum Operating Temperature | -30°C |
| Terminal type | Through Hole |
| Switching Function | Zero Cross Switching |
| Maximum Load Current | 3A |
| Standards/Approvals | cUL, IEC Rated, CE, RoHS |
| Pay online using | Or choose to pay later via bank transfer |
| RS Stock No. | 740-1340Brand: CrydomManufacturers Part No.: ED24D3R |
| Minimum Control Voltage | 3V dc |
| Maximum Control Voltage | 15V dc |
| Off State Leakage Current | 0.1mArms |
Key Features
- Rated for a maximum load voltage of 280 Vrms and load current up to 3 A.
- Designed for DIN rail mounting and through-hole terminal installation.
- Operates within a temperature range of -30°C to +80°C for durability in demanding environments.
- Features zero-cross switching functionality to reduce electrical noise during operation.
- Equipped with an LED input status indicator for easy monitoring of relay activation.
- Supports minimum control voltage of 3 V DC and maximum of 15 V DC for flexible control options.
- Compact dimensions measuring 29 mm in length, 12.7 mm in width, and 37.4 mm in height.
- Ensures low off-state leakage current of 0.1 mArms and low output capacitance of 10 pF.
Product Description
Crydom ED24D3R is a solid state relay from the ED Series, engineered to deliver robust and reliable switching for AC load circuits in industrial and automation applications. With a maximum load current of 3 A and load voltage capacity of 280 Vrms, this relay is suitable for precise control in demanding electrical environments.
Its DIN rail mount and through-hole terminal type design provide flexible and secure installation options within control panels or on printed circuit boards. The relay supports operating temperatures ranging from -30°C to +80°C, making it ideal for use in harsh or variable conditions common in industrial, manufacturing, and HVAC systems.
The zero-cross switching function minimizes electromagnetic interference and prolongs component lifespan by ensuring the relay switches only when the AC voltage crosses zero. The presence of an LED input status indicator offers immediate visual confirmation of device operation, enhancing system monitoring and maintenance activities.
Compact dimensions of 29 mm length, 12.7 mm width, and 37.4 mm height allow installation in tight spaces without sacrificing performance. The product complies with major international standards including cUL, IEC, CE, and RoHS, reflecting high safety and environmental compliance.
3 A rated load current and 280 Vrms maximum load voltage. DIN rail mount and through-hole terminal configurations for versatile installation. Wide operating temperature range from -30°C to 80°C. Zero-cross switching to reduce electrical noise and wear.
LED input status indicator to monitor relay state. Low off-state leakage current of 0.1 mArms. Compact size for space-saving integration. Compliance with international safety and environmental standards.
This solid state relay is well-suited for industrial automation, electrical circuit control, manufacturing process equipment, and HVAC systems requiring efficient and reliable switching solutions. Its durable design and certifications assure long operational life and regulatory compliance.
Explore Crydom’s ED Series Solid State Relays in the Electronics & Electricals category at EnvMart for trusted performance in your control applications.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The solid state relay has a maximum load voltage of 280 Vrms and can handle a load current of up to 3 A.
This model operates within a temperature range of -30°C to +80°C, making it suitable for various industrial environments.
It is designed for DIN rail mounting and also supports through-hole terminal installation for flexible setup options.
Zero-cross switching minimizes electromagnetic interference and prolongs the lifespan of the relay by ensuring it switches only when the AC voltage crosses zero.
The dimensions of this solid state relay are 29 mm in length, 12.7 mm in width, and 37.4 mm in height.
The relay supports a minimum control voltage of 3 V DC and a maximum of 15 V DC, allowing for flexible control options.
The off-state leakage current is low, rated at 0.1 mArms, which contributes to its efficiency.
This relay complies with several international standards including cUL, IEC Rated, CE, and RoHS.
The output type of this solid state relay is AC, making it suitable for controlling AC load circuits.
This solid state relay is well-suited for industrial automation, electrical circuit control, manufacturing process equipment, and HVAC systems.
The relay has a low output capacitance of 10 pF, which helps in reducing electrical noise during operation.
The solid state relay is manufactured in Mexico, reflecting its origin in a region known for electronics production.
