Panasonic Surge Absorber Varistor 56 V, Capacitance 6.5 nF, Clamping Voltage 110 V, Clamping Current 10 A, Model ERZV14D560
Specifications
| Country of Origin | Japan |
|---|---|
| Diameter | 15.5mm |
| Brand | Panasonic |
| THICKNESS | 5.1mm |
| Length | 38.5mm |
| Model | ERZV14D560 |
| Packaging | Bulk |
| Series | V |
| Energy Rating | 16J |
| Maximum Operating Temperature | 85°C |
| Capacitance | 6.5nF |
| Minimum Operating Temperature | -40°C |
| Maximum dc Voltage | 45V dc |
| Standards/Approvals | UL 1449, VDE, CQC, CSA |
| Pay online using | Or choose to pay later via bank transfer |
| RS Stock No. | 720-9939PBrand: PanasonicManufacturers Part No.: ERZV14D560 |
| Lead Pitch | 7.5mm |
| Maximum AC Voltage | 35V ac |
| Clamping Voltage VC | 110V |
| Clamping Current | 10A |
| Maximum Surge Current | 2kA |
| Varistor Voltage | 56 V |
Key Features
- Operates with a clamping voltage of 110 V to protect against voltage spikes.
- Maximum surge current capability of 2 kA ensures robust transient voltage suppression.
- Compact dimensions include 15.5 mm diameter and 38.5 mm length.
- Designed to operate within temperature range of -40°C to 85°C for reliable performance.
- Features a 7.5 mm lead pitch for easy PCB mounting.
- Energy rating of 16 joules supports high surge energy absorption.
- Complies with UL 1449, VDE, CQC, and CSA standards for safety and quality assurance.
- Varistor component type for use in electronic surge protection applications.
Product Description
Panasonic ERZV14D560 Surge Absorber is a metal oxide varistor designed for advanced transient voltage suppression in electronic and electrical components. This varistor features a nominal voltage rating of 56 V and a capacitance of 6.5 nF, making it suitable for filtering and surge protection in sensitive circuits.
It has a clamping voltage of 110 V and can handle clamping currents up to 10 A, providing effective protection against voltage spikes and surges up to 2 kA. The device has a diameter of 15.5 mm, length of 38.5 mm, and thickness of 5.1 mm, with a lead pitch of 7.5 mm facilitating easy PCB integration.
Operating temperature ranges from -40°C to 85°C enable reliability in a wide variety of industrial and commercial environments. Compliance with UL 1449, VDE, CQC, and CSA standards ensures the varistor meets international safety and quality requirements for surge protection components.
This product is typically supplied in bulk packaging, suitable for manufacturing and assembly environments requiring efficient production. Operates with a clamping voltage of 110 V to protect against voltage spikes. Maximum surge current capability of 2 kA ensures robust transient voltage suppression.
Compact dimensions include 15.5 mm diameter and 38.5 mm length. Designed to operate within temperature range of -40°C to 85°C for reliable performance. Features a 7.5 mm lead pitch for easy PCB mounting. Energy rating of 16 joules supports high surge energy absorption.
Complies with UL 1449, VDE, CQC, and CSA standards for safety and quality assurance. Varistor component type for use in electronic surge protection applications. This Varistor is ideal for industrial, electronics manufacturing, power supply components, and consumer electronics applications requiring transient voltage protection.
Explore the Electronics Components category on EnvMart for more surge protection and passive components from Panasonic and other leading brands.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The clamping voltage of this varistor is 110 V, providing effective protection against voltage spikes.
This model has a maximum surge current capability of 2 kA, ensuring robust transient voltage suppression.
The varistor has a diameter of 15.5 mm, a length of 38.5 mm, and a thickness of 5.1 mm.
The capacitance of this varistor is 6.5 nF, which is suitable for filtering and surge protection in sensitive circuits.
It operates within a temperature range of -40°C to 85°C, allowing for reliable performance in various environments.
This varistor complies with UL 1449, VDE, CQC, and CSA standards, ensuring safety and quality assurance.
The energy rating of this varistor is 16 joules, supporting high surge energy absorption.
The lead pitch of this model is 7.5 mm, facilitating easy PCB mounting.
The maximum AC voltage rating for this varistor is 35 V AC.
The maximum DC voltage rating for this model is 45 V DC.
This varistor is suitable for use in electronic surge protection applications, including industrial and consumer electronics.
The country of origin for this varistor is Japan.
