Preci-Dip 800 Series Straight Surface Pin Header 6 Contacts 2.54 mm Pitch 1 Row Unshrouded 800-80-006-30-001191

Preci-Dip 800-80-006-30-001191 Straight Surface Pin Header is part of the 800 Series IC pin connectors, engineered for precision electronic PCB applications. Featuring 6 contacts with a 2.54 mm pitch and a single row layout, this unshrouded header is optimized for surface mount soldering, making it ideal in compact device assemblies.

The housing material is made from fibreglass reinforced polyethylene terephthalate which provides excellent thermal stability and mechanical durability, enabling the connector to function in operating temperatures ranging from -55°C to 125°C. The contacts are crafted from brass with tin plating to ensure superior electrical conductivity and long-term corrosion resistance.

This pin header is rated for a maximum of 3 Amps current and 150 Volts voltage, ensuring safe and efficient power transmission in electronic circuits. Its unshrouded design offers straightforward access to the brass pins during soldering, and the surface mount termination type supports robust mechanical and electrical connections to the PCB.

Common uses include industrial electronics manufacturing, laboratory equipment, communication devices, and other applications requiring reliable, compact, and high-quality PCB connectors. The Swiss origin signifies adherence to high manufacturing and quality control standards, suitable for commercial and industrial uses.

The pin header has 6 male contacts arranged in a single row for compact PCB design integration. Constructed with a fibreglass reinforced polyethylene terephthalate housing for thermal and mechanical strength. The brass contact material is plated with tin to enhance conductivity and corrosion resistance.

Designed for surface mount applications with solder termination ensuring durable electrical connections. Operates reliably within a temperature range of -55°C to 125°C, suitable for harsh environments. Rated for a maximum voltage of 150 V and current of 3 A ensuring safe use in electrical circuits.

Unshrouded design allows easy access to pin contacts and simplifies soldering processes. Pitch size of 2.54 mm aligns with standard PCB layout specifications. Manufactured in Switzerland maintaining strict quality standards for industrial use.

This connector is ideal for use in electronic assembly lines, PCB designs for computing, communications, and power supply applications. Its reliable construction supports long service life and efficient electrical performance.

Explore the range of Preci-Dip connectors for various configurations and packaging options on EnvMart for your electronic component sourcing needs.

Explore more products in our PCB Headers category.
