Preci-Dip 850 Series Straight Surface Pin Header, 12 Contacts, 1.27 mm Pitch, 1 Row, Unshrouded 850-80-012-30-001101

Free Delivery in India | Lowest Global Shipping Charges

Preci-Dip 850 Series Straight Surface Pin Header, 12 Contacts, 1.27 mm Pitch, 1 Row, Unshrouded 850-80-012-30-001101

Name: Preci-Dip 850 Series Straight Surface Pin Header, 12 Contacts, 1.27 mm Pitch, 1 Row, Unshrouded 850-80-012-30-001101
Brand: Preci-Dip
SKU: 353578
Price: 4.34 USD
Availability: InStock



Category PCB Headers Brand Preci-Dip Condition New

Specifications

Country of Origin	Switzerland
Voltage	150V
Brand	Preci-Dip
Orientation	Straight
Current	1A
Mount Type	Surface
Housing Material	Fibreglass Reinforced Polyethylene Terephthalate
Contact Material	Brass
Series	850
Termination Type	Solder
Maximum Operating Temperature	125°C
Minimum Operating Temperature	-55°C
Number of Rows	1
Pitch	1.27mm
Pay online using	Or choose to pay later via bank transfer
Contact Plating	Tin
Number of Contacts	12
Contact Gender	Male
Shrouded/Unshrouded	Unshrouded

Key Features

Offers 12 male contacts arranged in a single straight row.
Constructed with brass contacts plated with tin for corrosion resistance.
Housing made of fibreglass reinforced polyethylene terephthalate for durability.
Supports a voltage rating of 150V and current rating of 1A.
Designed for surface mount with unshrouded pins and solder termination.
Operates safely within temperature range of -55°C to 125°C.
Ideal for PCB connection applications in electronics and electrical industries.

Product Description

Preci-Dip 850-80-012-30-001101 is a part of the 850 Series Straight Surface Pin Header family designed for precise and reliable PCB connectivity. This component features 12 male contacts arranged in a single straight row with a standard 1.27 mm pitch, ensuring compatibility with common PCB designs.

The housing is manufactured from fibreglass reinforced polyethylene terephthalate, providing excellent mechanical strength and thermal stability. Brass contacts are plated with tin, enhancing conductivity and resisting corrosion in harsh environments.

Engineered for surface mounting, this pin header is unshrouded, allowing straightforward solder termination to the PCB. It can safely operate within a temperature range from -55°C up to 125°C, and can handle voltages up to 150 volts with a current rating of 1 ampere, making it well-suited for a wide variety of electronic applications.

Its robust construction and reliable electrical characteristics make it ideal for industrial, commercial, and laboratory use where precise PCB connections are required. This product is manufactured in Switzerland and complies with UL 94V-0 flammability standards, ensuring safety and performance.

Offers 12 male contacts arranged in a single straight row. Constructed with brass contacts plated with tin for corrosion resistance. Housing made of fibreglass reinforced polyethylene terephthalate for durability. Supports a voltage rating of 150V and current rating of 1A.

Designed for surface mount with unshrouded pins and solder termination. Operates safely within temperature range of -55°C to 125°C. Ideal for PCB connection applications in electronics and electrical industries.

This pin header is an essential component for PCB assemblies across various industries including electronics manufacturing and electrical installations. Browse more high-quality PCB connectors and headers from Preci-Dip and other top brands on EnvMart to meet your project requirements.
