Preci-Dip 850 Series Straight Through Hole Pin Header 11 Contacts 1.27 mm Pitch 1 Row Unshrouded 850-80-011-10-001101

Preci-Dip 850-80-011-10-001101 straight through hole pin header is a high-quality PCB connector designed for industrial, electronic, and manufacturing applications. It features 11 male contacts arranged in a single row with standard 1.27 mm pitch spacing, making it suitable for compact circuit board designs.

The housing is made of fibreglass reinforced polyethylene terephthalate, offering excellent mechanical strength and thermal stability. Contacts are fabricated from brass and plated with tin for superior electrical performance and corrosion resistance. The header supports through hole mount type with solder termination ensuring reliable mechanical and electrical connection on printed circuit boards.

Operating temperature ranges from -55°C to 125°C, allowing use in diverse environments including industrial controls, telecommunications, consumer electronics, and instrumentation. Rated for 1 amp current and 150 volts, this connector is optimized for low-power signal and power transmission.

The unshrouded design of the straight male contacts permits easy soldering and inspection, while its compact body height (~2.2 mm) and tail length (~2.9 mm) ensure space-efficient mounting. The product complies with UL 94V-0 flammability standards enhancing safety in demanding applications.

This Preci-Dip 850 series pin header is ideal for electrical assemblies requiring precise, durable PCB connections in sectors such as electronics manufacturing, laboratory instrumentation, HVAC control systems, and automotive electronics.

Manufactured with fibreglass reinforced polyethylene terephthalate housing for high durability. Brass contact material with tin plating ensures excellent electrical conductivity and corrosion resistance. Designed for through hole mounting and solder termination for secure assembly.

Operates reliably within a temperature range of -55°C to 125°C. Rated for 1 amp current and 150 volts maximum operating voltage. Body height of approximately 2.2 mm and tail length around 2.9 mm for precise mounting. Suitable for industrial electronic assemblies requiring compact and reliable connectors.

Unshrouded male contacts allow flexible wire routing and connection configurations. Complies with UL 94V-0 standards for safety in electronic components. Explore the Preci-Dip range of PCB Headers and connectors on EnvMart for trusted industrial-grade electronic components supporting your manufacturing and design needs.
