Panasonic Through Hole High Frequency Relay 12V DC Coil 3 GHz Max Coil Frequency SPDT ARS14A12
Specifications
| Country of Origin | Japan |
|---|---|
| Brand | Panasonic |
| Height | 8mm |
| Length | 14.6mm |
| Model | ARS14A12 |
| Mount Type | Through Hole |
| Isolation | 30dB |
| Contact Material | Gold Plated |
| Series | ARS |
| Maximum Operating Temperature | 70°C |
| Coil Type | Non-Latching |
| Contact Configuration | SPDT |
| Minimum Operating Temperature | -40°C |
| Terminal type | Solder |
| Contact Resistance | 100mΩ |
| Pay online using | Or choose to pay later via bank transfer |
| RS Stock No. | 699-6673 Brand: [Panasonic](https://in.rsdelivers.com/brands/panasonic)Manufacturers Part No.: ARS14A12 |
| Coil Resistance | 720Ω |
| Coil Power | 200mW |
| Insertion Loss | 0.4dB |
| Maximum Coil Frequency | 3GHz |
Key Features
- Compact super miniature design measuring approximately 14.6 mm length and 8 mm height.
- Non-latching coil type with 720 ohms coil resistance ensuring efficient operation.
- Gold plated contacts with contact resistance of 100 milliohms for reliable signal transmission.
- Insertion loss of 0.4 dB and isolation of 30 dB suitable for high frequency signal applications.
- Operating temperature range from -40°C to 70°C for durability in varying environments.
- Designed for solder terminal and through hole mounting type for easy PCB integration.
- Coil power consumption is 200 mW enabling low power relay switching.
Product Description
Panasonic ARS14A12 is a high frequency relay designed for through hole mounting applications with a 12V DC coil. It offers excellent high frequency characteristics up to 3 GHz, making it ideal for demanding RF switching needs in broadcasting, video, measurement, mobile phone base stations, and communication equipment. The relay features a compact super miniature design measuring 14.6 mm in length and 8 mm in height, facilitating layout efficiency in tight spaces.
This relay utilizes non-latching coil technology with a coil resistance of 720 ohms and low coil power consumption of 200 mW. Its contact configuration is Single Pole Double Throw (SPDT) with gold plated contacts to minimize contact resistance and maximize reliability. The relay maintains excellent signal integrity with insertion loss as low as 0.4 dB and isolation of 30 dB, combined with a Voltage Standing Wave Ratio (VSWR) of 1.4 at 3 GHz.
Designed for robust operation, the ARS14A12 performs over a wide temperature range from -40°C to 70°C and is mounted via through hole solder terminals for PCB assembly. It is part of Panasonic's ARS series of high frequency relays manufactured in Japan, ensuring quality and performance consistency. This relay is suitable for industrial, telecommunications, laboratory, and broadcast applications where reliable high frequency switching is essential.
Compact super miniature design measuring approximately 14.6 mm length and 8 mm height. Non-latching coil type with 720 ohms coil resistance ensuring efficient operation. Gold plated contacts with contact resistance of 100 milliohms for reliable signal transmission.
Insertion loss of 0.4 dB and isolation of 30 dB suitable for high frequency signal applications. Operating temperature range from -40°C to 70°C for durability in varying environments. Designed for solder terminal and through hole mounting type for easy PCB integration.
Voltage Standing Wave Ratio (VSWR) of 1.4 at 3 GHz ensuring signal integrity. Coil power consumption is 200 mW enabling low power relay switching. Explore the Panasonic range of high frequency relays and related products at EnvMart for your industrial, communication, and electronic system requirements.
Explore more products in our HF & RF Relays category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This relay has a maximum coil frequency of 3 GHz, making it suitable for high frequency applications.
The coil resistance of this relay is 720 ohms, which ensures efficient operation.
The coil power consumption for this relay is 200 mW, enabling low power relay switching.
This relay has an insertion loss of 0.4 dB, which is beneficial for maintaining signal integrity in high frequency applications.
The operating temperature range for this relay is from -40°C to 70°C, allowing it to function in various environmental conditions.
This model is designed for through hole mounting, which facilitates easy integration onto PCBs.
The contacts of this relay are gold plated, which minimizes contact resistance and enhances reliability.
This relay provides an isolation of 30 dB, which is critical for preventing signal interference in high frequency applications.
The relay measures approximately 14.6 mm in length and 8 mm in height, making it compact for tight spaces.
The voltage standing wave ratio (VSWR) for this relay is 1.4 at 3 GHz, ensuring good signal integrity.
The AA12 relay is manufactured in Japan, ensuring quality and performance consistency.
