Omron High Frequency Surface Mount Relay DPDT 5V DC Coil 1GHz Max Coil Frequency G6KU-2F-RF 5DC
Specifications
| Country of Origin | Japan |
|---|---|
| Frequency | Relay, 5V dc Coil, 1 GHz Max |
| Brand | Omron |
| Height | 5.4mm |
| Length | 12.8mm |
| Model | G6KU-2F-RF 5DC |
| Mount Type | Surface |
| Contact Material | Silver Alloy |
| Maximum Operating Temperature | 70°C |
| Coil Type | Latching |
| Contact Configuration | DPDT |
| Minimum Operating Temperature | -40°C |
| Contact Resistance | 100mΩ |
| Standards/Approvals | RoHS |
| Coil Resistance | 237Ω |
| Coil Power | 100mW |
| Contact Current | 1A |
| Maximum Coil Frequency | 1GHz |
Key Features
- Features a 5V DC coil with a coil resistance of 237 ohms.
- Silver alloy contact material ensures reliable conductivity.
- Contact current rating of 1A suitable for signal switching applications.
- Compact surface mount design with dimensions 12.8mm length and 5.4mm height.
- Operating temperature range from -40°C to 70°C for versatile use environments.
- Low coil power consumption of approximately 100mW for energy-efficient operation.
- Fully sealed construction provides durability and resistance to contaminants.
- Complies with RoHS standards for environmental safety.
Product Description
Omron G6KU-2F-RF 5DC is a high frequency surface mount relay designed for applications requiring reliable DPDT switching with excellent high-frequency characteristics up to 1 GHz. This miniature SMT relay measures 12.8mm in length and 5.4mm in height, suitable for compact PCB layouts in industrial, telecommunications, and signal conditioning equipment.
The relay features a 5V DC coil with a resistance of 237 ohms and low power consumption of just 100mW, making it energy efficient. The contact material is silver alloy providing low contact resistance of 100mΩ and supports a contact current of up to 1A. Its fully sealed construction ensures durability in demanding environments while maintaining performance across a temperature range of -40°C to 70°C.
Designed with superior isolation characteristics, the relay offers a minimum 20 dB isolation between contacts of the same polarity and 30 dB between different polarities, with a maximum insertion loss of 0.2 dB. This makes it ideal for high-frequency switching with minimal signal loss in RF applications.
The surface mount package with outside-L terminals simplifies PCB assembly processes and integration into automated manufacturing. Its compliance with RoHS standards and origin from Japan guarantee a high level of quality and environmental compliance.
This relay is used widely in industrial automation systems, telecommunications equipment, laboratory instrumentation, and other high-frequency electronic devices where precision relay switching is critical.
Features a 5V DC coil with coil resistance of 237 ohms. Contact configuration is DPDT with 1A contact current rating. Compact surface mount form factor measuring 12.8mm x 5.4mm. Operates reliably from -40°C to 70°C, suitable for harsh environments.
Low coil power consumption of 100mW maximizes energy efficiency. Fully sealed and robust construction enhances durability. Silver alloy contacts ensure low resistance and high conductivity. Complies with RoHS environmental standards.
Manufactured in Japan, reflecting superior quality. Explore our full range of HF & RF relays and other Omron electrical components at EnvMart for trusted performance and industry-grade reliability.
Explore more products in our HF & RF Relays category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model can handle a maximum coil frequency of 1 GHz, making it suitable for high-frequency applications.
It features a DPDT (Double Pole Double Throw) contact configuration, allowing for versatile switching options.
It operates with a 5V DC coil and has a coil resistance of 237 ohms.
The contact current rating is 1A, suitable for signal switching applications.
The relay measures 12.8mm in length and 5.4mm in height, making it compact for PCB layouts.
It operates reliably in a temperature range from -40°C to 70°C, suitable for various environments.
It uses silver alloy as the contact material, ensuring low contact resistance of 100mΩ.
Yes, it complies with RoHS standards, ensuring environmental safety in its materials and manufacturing.
The coil power consumption is approximately 100mW, contributing to its energy-efficient operation.
It offers a minimum of 20 dB isolation between contacts of the same polarity and 30 dB between different polarities.
This model supports surface mounting, making it easy to integrate into PCB designs.
It is manufactured in Japan, reflecting a commitment to quality in its production.
