Panasonic Through Hole High Frequency Relay 12V DC Coil 3GHz Max Coil Frequency SPDT ARS12A12
Specifications
| Country of Origin | Japan |
|---|---|
| Frequency | Relay, 12V dc Coil, 3 GHz Max |
| Brand | Panasonic |
| Height | 8mm |
| Length | 14.6mm |
| Model | ARS12A12 |
| Mount Type | Through Hole |
| Isolation | 30dB |
| Contact Material | Gold Plated |
| Series | ARS |
| Maximum Operating Temperature | 70°C |
| Coil Type | 2 Coil Latching |
| Contact Configuration | SPDT |
| Minimum Operating Temperature | -40°C |
| Terminal type | Solder |
| Contact Resistance | 100mΩ |
| Coil Resistance | 360Ω |
| Coil Power | 400mW |
| Insertion Loss | 0.5dB |
| Maximum Coil Frequency | 3GHz |
Key Features
- Compact super miniature size of 14.6mm length and 8mm height.
- Gold plated contact material for reliable signal transfer and minimal resistance.
- Coil resistance of 360 ohms and coil power of 400mW ensures efficient operation.
- Excellent high frequency characteristics with 0.5dB insertion loss and 30dB isolation.
- Suitable for broadcasting, video, communications, and measurement uses.
- Through hole mounting with solder terminals for secure PCB installation.
- Operates reliably in temperature range from -40°C to 70°C.
- 2 coil latching type coil configuration for stable switching.
Product Description
Panasonic ARS12A12 is a high frequency through hole relay designed for high performance switching up to 3GHz frequencies, powered by a 12V DC coil. This super miniature relay measures 14.6mm in length and 8mm in height, making it ideal for compact electronic applications. It features SPDT contact configuration with gold plated contacts for superior conductivity and signal integrity.
The relay provides low insertion loss of 0.5dB and high isolation of 30dB, making it highly suitable for RF and microwave circuits, including broadcasting equipment, video devices, mobile phone base stations, and various measurement instruments. The coil resistance is rated at 360 ohms with 400mW coil power consumption, optimized for minimal power usage.
Designed for through hole mounting with solder terminals, it enables reliable mechanical connection on printed circuit boards. The relay operates well in harsh environments with a wide temperature range from -40°C to 70°C. The 2 coil latching type offers secure and stable switching states for critical applications.
Compact super miniature design with 14.6mm length and 8mm height. Gold plated contacts ensure minimal contact resistance and high signal quality. High frequency support up to 3GHz with low insertion loss and high isolation.
Coil resistance 360Ω and coil power 400mW for efficient operation. SPDT contact configuration for versatile switching functions. Through hole mounting with solder terminals for PCB applications. Wide operating temperature range from -40°C to 70°C.
2 coil latching coil type for stable and reliable switching.
This product is manufactured in Japan and is suitable for use in industrial, communication, broadcasting, laboratory, and measurement systems. The ARS12A12 model from Panasonic offers high reliability and precision for demanding high frequency relay applications.
Explore more products in our HF & RF Relays category.
