STMicroelectronics Schottky Barrier Diode 30 V 100 mA 3-Pin SOT-23 BAR43AFILM

Free Delivery in India | Lowest Global Shipping Charges

STMicroelectronics Schottky Barrier Diode 30 V 100 mA 3-Pin SOT-23 BAR43AFILM

Name: STMicroelectronics Schottky Barrier Diode 30 V 100 mA 3-Pin SOT-23 BAR43AFILM
Brand: STMicroelectronics
SKU: 350270
Price: 0.05 USD
Availability: InStock



Category Schottky Diode Brand STMicroelectronics Condition New

Specifications

Country of Origin	India
Brand	STMicroelectronics
Height	0.95mm
Length	2.9mm
Model	BAR43AFILM
Width	1.3mm
Mount Type	Surface
Series	BAR43
Maximum Operating Temperature	150°C
Package Type	SOT-23
Minimum Operating Temperature	-65°C
Pin Count	3
Maximum Continuous Forward Current If	100mA
Peak Reverse Repetitive Voltage Vrrm	30V
Diode Configuration	Common Anode
Rectifier Type	Schottky
Peak Reverse Current Ir	500nA
Peak Non-Repetitive Forward Surge Current Ifsm	750mA
Maximum Forward Voltage Vf	1V
Peak Reverse Recovery Time trr	5ns

Key Features

Features a maximum continuous forward current of 100 mA for reliable operation.
Supports peak reverse repetitive voltage of 30 V suitable for low voltage circuits.
Surface mount type with compact SOT-23 package for space saving.
Exhibits a maximum forward voltage drop of 1 V to reduce power loss.
Has peak reverse current of only 500 nA ensuring low leakage.
Operates at temperature range from -65°C to 150°C for harsh environments.
Fast peak reverse recovery time of 5 ns for efficient switching applications.
Package dimensions are 2.9 mm length, 1.3 mm width, and 0.95 mm height.

Product Description

STMicroelectronics BAR43AFILM Schottky Barrier Diode 30 V 100 mA 3-Pin SOT-23 is an advanced semiconductor device designed for efficient rectification and low forward voltage drop.

This diode supports a maximum continuous forward current of 100 mA and a peak reverse repetitive voltage of 30 V, making it highly suitable for low voltage electronic applications.

Housed in a compact surface mount SOT-23 package, it integrates easily into space-constrained circuit boards. The diode has a fast peak reverse recovery time of 5 ns, enhancing switching performance in power and signal circuits.

Its robust temperature tolerance ranges between -65°C minimum operating temperature and 150°C maximum operating temperature, allowing reliability in harsh industrial, automotive, and electronic environments.

The device's low peak reverse current of 500 nA ensures minimal leakage, and a maximum forward voltage drop of 1 V contributes to power efficiency. The physical dimensions are 2.9 mm length, 1.3 mm width, and 0.95 mm height, with a 3-pin common anode configuration, making it versatile for multiple circuit designs.

Maximum continuous forward current: 100 mA. Peak reverse repetitive voltage: 30 V. Surface mount, SOT-23 package. Maximum forward voltage: 1 V. Peak reverse current: 500 nA. Operating temperature range: -65°C to 150°C. Peak reverse recovery time: 5 ns.

Dimensions: 2.9 mm x 1.3 mm x 0.95 mm. 3-pin common anode configuration.

This Schottky diode is ideal for use in power electronics, signal processing, and electronic component manufacturing, supporting industrial, laboratory, automotive, and general electronics sectors.
