Texas Instruments Operational Amplifier 700 kHz Gain Bandwidth, 8-Pin MSOP Package, 26V Max Supply LM2904DGKR
Specifications
| Country of Origin | India |
|---|---|
| Brand | Texas Instruments |
| Height | 0.97mm |
| Length | 3mm |
| Model | LM2904DGKR |
| Width | 3mm |
| Mount Type | Surface |
| Series | LM2904 |
| Output Current | -10mA |
| Maximum Operating Temperature | 125°C |
| Package Type | MSOP |
| Minimum Operating Temperature | -40°C |
| Number Of Channels | 2 |
| Standards/Approvals | RoHS |
| Pin Count | 8 |
| Maximum Supply Voltage | 26V |
| Minimum Supply Voltage | 5V |
| GBP - Gain Bandwidth Product | 700kHz |
| Input Bias Current | -500 nA |
| Vos - Input Offset Voltage | 10 mV |
| Slew Rate | 0.3V/μs |
| Input Offset Current | 300 nA |
Key Features
- Surface mount MSOP package for space-saving PCB design.
- Dual channel operational amplifier supports a wide voltage range of 5V to 26V.
- Low input bias current of -500 nA enables precision signal processing.
- Operating temperature range from -40°C to 125°C for versatile industrial use.
- Input offset voltage of 10 mV and slew rate of 0.3 V/μs for stable amplification.
- Output current capability of -10 mA meets common driving requirements.
- RoHS compliant ensuring environmental safety and compliance.
Product Description
Texas Instruments LM2904DGKR is a dual general purpose operational amplifier designed for a wide range of electronic applications. Featuring a gain bandwidth product of 700 kHz and housed in a compact 8-pin MSOP surface mount package, this device is ideal for precision amplification in electronics circuits requiring low power consumption and stable performance over varying operating conditions.
The amplifier operates with a supply voltage range of 5V minimum to 26V maximum, maintaining reliable function across industrial and commercial temperature ranges from -40°C to 125°C. Its input offset voltage of 10 mV and low input bias current of -500 nA ensure accurate signal processing, while the slew rate of 0.3 V/μs contributes to its responsiveness in dynamic circuits.
This component provides an output current capability of -10 mA suitable for driving typical loads in amplifier and comparator circuits. It fully complies with RoHS standards to meet environmental protection requirements.
The LM2904 series from Texas Instruments is well known for its versatility in operational amplifier applications including signal conditioning, audio amplification, and sensor interfacing in industrial, laboratory, and electronic manufacturing environments.
Surface mount MSOP package for efficient PCB space utilization. Wide operating voltage and temperature ranges ensure broad application compatibility. Low input bias current and offset voltage reduce signal distortion. Robust output current capacity suitable for diverse circuit designs.
RoHS compliant component supporting environmental safety standards. Compact size dimensions facilitate integration into space-constrained electronics.
Choose the LM2904DGKR Operational Amplifier from Texas Instruments for reliable performance in your precision electronic circuit designs. Explore more components like this in our Electronics & Electricals catalog on EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The gain bandwidth product of this operational amplifier is 700 kHz, making it suitable for various precision amplification applications.
It operates with a supply voltage range from 5V to 26V, allowing for versatility in different electronic applications.
The input bias current is -500 nA, which helps in reducing signal distortion during processing.
It has an output current capability of -10 mA, suitable for driving typical loads in amplifier and comparator circuits.
The dimensions of this operational amplifier are 3 mm in length, 3 mm in width, and 0.97 mm in height, making it compact for PCB design.
The operating temperature range is from -40°C to 125°C, which allows for its use in various industrial environments.
The input offset voltage is 10 mV, which contributes to its accuracy in signal processing applications.
It comes in an 8-pin MSOP surface mount package, designed for efficient PCB space utilization.
Yes, it is RoHS compliant, ensuring it meets environmental safety and compliance standards.
This model features two channels, making it suitable for dual signal processing applications.
The slew rate is 0.3 V/μs, which indicates its responsiveness in dynamic circuits.
The country of origin for this operational amplifier is India.
