Omron Power Relay, PCB Mount, 48V DC Coil, 12A Switching Current, SPDT Contact Configuration G2RL-14 DC48

Omron G2RL-14 DC48 is a high-performance PCB mount power relay featuring a 48V DC coil and robust 12A switching current capacity with SPDT contact configuration. This relay is specifically designed for reliability and compactness in electrical and automation applications.

The relay offers a coil power of 400mW and a coil resistance of 5.4kΩ, ensuring energy-efficient operation. It supports a switching power of 3 kVA, with the capability to switch DC voltages up to 300V and AC voltages up to 440V, accommodating a wide range of control requirements.

Constructed with a silver alloy contact material, the relay provides excellent conductivity and low contact resistance of 100mΩ, enhancing its durability and performance. Its compact dimensions (29mm length x 12.7mm width x 15.7mm height) make it ideal for tight PCB mounting spaces.

The Omron G2RL-14 DC48 is designed to maintain performance across a broad operating temperature range from -40°C to 85°C. It meets critical industry standards including RoHS directives, IEC/EN 60079-15 for explosive atmospheres, and VDE certifications, confirming its quality and safety suitability for demanding environments.

This power relay is widely used in industrial automation, control panels, HVAC systems, manufacturing machinery, and electronic equipment requiring reliable switching with compact form factor.

This power relay operates at a coil voltage of 48V DC with a coil power consumption of 400mW. Designed with a single pole double throw (SPDT) contact configuration to enable versatile switching applications. Rated switching current is 12 amps for reliable control in high power circuits.

Features a compact, low-profile design measuring 29mm length, 12.7mm width, and maximum height of 15.7mm suitable for PCB mounting. Contact material is silver alloy ensuring low contact resistance and long service life. Operating temperature ranges from -40°C up to 85°C, supporting varied industrial conditions.

Switching power capability up to 3 kVA with DC switching voltage of 300V and AC switching voltage up to 440V. Coil resistance is 5.4kΩ and contact resistance is 100mΩ, ensuring efficient electrical performance. Compliance with standards including RoHS, IEC/EN 60079-15 and VDE certifications ensures quality and safety.

Suitable for industrial, automation, electrical control panel, and electronic equipment applications. Explore other Omron Power Relays and components in the Electronics & Electricals category at EnvMart for high-quality industrial solutions.
