Vishay 1-Element Bi-Directional Transient Voltage Suppressor Diode 600 W, 2-Pin DO-214AA SMBJ26CA-E3/52

Free Delivery in India | Lowest Global Shipping Charges

Vishay 1-Element Bi-Directional Transient Voltage Suppressor Diode 600 W, 2-Pin DO-214AA SMBJ26CA-E3/52

Name: Vishay 1-Element Bi-Directional Transient Voltage Suppressor Diode 600 W, 2-Pin DO-214AA SMBJ26CA-E3/52
Brand: Vishay
SKU: 343480
Price: 20.22 USD
Availability: InStock



Category Transient Voltage Suppressor Brand Vishay Condition New

Specifications

Country of Origin	India
Brand	Vishay
Height	2.24mm
Length	4.57mm
Model	SMBJ26CA-E3/52
Width	3.94mm
Mount Type	Surface
Series	TRANSZORB TVS
Maximum Operating Temperature	150°C
Package Type	DO-214AA (SMB)
Minimum Operating Temperature	-55°C
Pin Count	2
Number of Elements per Chip	1
Clamping Voltage VC	42.1V
Automotive Standard	AEC-Q101
Diode Configuration	Single
Direction Type	Bi-Directional
Minimum Breakdown Voltage Vbr	28.9V
Maximum Reverse Stand-off Voltage Vwm	26V
Peak Pulse Power Dissipation Pppm	600W
Test Current It	1mA
Maximum Peak Pulse Current Ippm	14.3A
Maximum Reverse Leakage Current	1μA

Key Features

Designed for bi-directional voltage transient suppression.
Minimum breakdown voltage of 28.9 V ensures effective clamping.
Surface mount device with reliable DO-214AA (SMB) package type.
Excellent ESD protection meeting AEC-Q101 automotive standards.
Operates within temperature range from -55°C to 150°C for versatile applications.
Clamping voltage rating at 42.1 V delivers robust surge protection.
Supports a maximum peak pulse current of 14.3 A to handle transient bursts.
Low maximum reverse leakage current of 1 μA reduces standby losses.

Product Description

Vishay SMBJ26CA-E3/52 is a 1-element bi-directional transient voltage suppressor diode engineered for reliable surge protection in sensitive electronic circuits. It provides a peak pulse power dissipation of 600 W within a compact 2-pin surface mount DO-214AA package, making it suitable for space-constrained PCB designs.

This diode features a minimum breakdown voltage of 28.9 V and a maximum reverse stand-off voltage of 26 V, offering excellent voltage clamping performance with a clamping voltage of 42.1 V. The device operates efficiently within a broad temperature range from -55°C to 150°C, meeting the stringent requirements of automotive applications thanks to compliance with AEC-Q101 standards.

With a test current of 1 mA and a maximum peak pulse current rating of 14.3 A, it is optimized for fast response and low incremental surge resistance. Its maximum reverse leakage current is only 1 μA, which minimizes power loss during normal operation.

The diode's physical dimensions are 4.57 mm in length, 3.94 mm in width, and 2.24 mm in height, ensuring ease of integration on standard PCBs. As part of the TRANSZORB TVS series, it offers superior transient voltage suppression for industrial, automotive, telecommunications, and consumer electronics.

Designed for bi-directional transient voltage suppression to protect circuits from voltage spikes. Compact DO-214AA surface mount package supports efficient PCB layout. Compliance with automotive AEC-Q101 standard for rigorous quality and reliability.

Wide operating temperature range from -55°C to 150°C for diverse environments. High pulse power dissipation of 600 W for robust surge handling capability. Low leakage current and fast response time reduce energy waste and boost protection.

Ideal for use in industrial, automotive, and telecommunication equipment. Explore more Transient Voltage Suppressor diodes and related semiconductor components in the Electronics & Electricals category on EnvMart.
