Vishay 1-Element Uni-Directional Transient Voltage Suppressor 1500W, Surface Mount DO-214AB Package SMCJ100A-E3/57T

Vishay SMCJ100A-E3/57T is a 1-element uni-directional transient voltage suppressor (TVS) designed for surface mount technology (SMT) applications. It comes in a compact DO-214AB (SMC) package with 2 pins, optimized for protecting sensitive electronics against transient voltage spikes caused by electrostatic discharge (ESD), inductive load switching, lightning, and other transient events.

Featuring a peak pulse power dissipation rating of 1500 W, this TVS diode effectively clamps transient voltages to a safe level with a clamping voltage of 162 V and has a minimum breakdown voltage of 111 V. The device has a maximum reverse stand-off voltage of 100 V, ensuring that it remains non-conductive until a transient event occurs.

The component operates reliably over a wide temperature range from -55°C to 150°C, making it suitable for automotive and harsh industrial environments that demand durability and reliable protection. The device is compliant with the AEC-Q101 automotive standard, RoHS directive, and UL 94 V-0 safety standard for flame retardancy.

Measuring 7.11 mm in length, 6.22 mm in width, and 2.42 mm in height, the SMCJ100A-E3/57T occupies minimal space on printed circuit boards, facilitating compact design layouts. It supports peak pulse currents up to 9.3 A and offers excellent ESD protection with a maximum reverse leakage current of just 1 µA, preserving the integrity of sensitive electronic circuits.

The uni-directional design and single diode configuration provide targeted transient suppression, ideal for protecting AC and DC power lines, automotive electronics, industrial machinery, telecommunications, and consumer electronics from voltage transients.

Applications span automotive electronic systems, industrial control equipment, power supplies, and telecommunications devices where transient voltage suppression is critical to prevent damage and ensure safety.

Explore the Vishay SMCJ series for a comprehensive range of Transient Voltage Suppressors tailored to diverse voltage and power ratings. Ensure reliable transient voltage protection in your projects with Vishay TVS diodes.

This TVS diode safeguards electronic equipment from transient overvoltages effectively. Compact surface mount package supports modern PCB design requirements. High peak pulse power of 1500 W handles severe transient events.

Wide operating temperature range meets automotive and industrial demands. Compliance with industry standards guarantees quality and reliability. Low leakage current protects sensitive electronics without power loss. Automotive grade certification ensures suitability for vehicle electronics.

Uni-directional design supports various transient voltage protection applications. Minimal footprint allows for space-saving circuit layouts. Discover more electronic components and power connectors at EnvMart to complement your engineering needs and enhance your product designs.
