Vishay TRANSZORB® 1-Element Bi-Directional Surface Mount TVS Diode 1.5 kW 2-Pin SMC SMCJ7.5CA-E3/57T

Vishay SMCJ7.5CA-E3/57T is a 1-element bi-directional transient voltage suppressor (TVS) diode designed to protect sensitive electronic equipment from voltage spikes. It is configured as a surface mount device with a 2-pin SMC package, offering efficient transient voltage suppression with a peak pulse power dissipation rating of 1.5 kW.

This TVS diode provides excellent protection for electronic and electrical circuits by clamping transient voltages to safe levels, preventing damage to components due to voltage surges. The bi-directional diode configuration ensures it can be used effectively in both AC and DC voltage environments.

The device operates over a wide temperature range from -55°C to 150°C, which makes it suitable for use in harsh industrial, automotive, and consumer electronic applications. It features a low maximum reverse leakage current of 200 μA, contributing to reduced power losses and enhanced energy efficiency.

The SMCJ7.5CA-E3/57T complies with the AEC-Q101 automotive standard, assuring quality and reliability for automotive system protection. It offers a maximum peak pulse current of 116.3 A, clamping voltage of 12.9 V, and a minimum breakdown voltage of 8.33 V, enabling fast and effective transient suppression.

Typical applications include transient voltage suppression in communication devices, power supplies, industrial control, automotive electronics, and consumer devices. The diode’s compact dimensions (7.11 mm x 6.22 mm x 2.42 mm) and surface mount form factor facilitate high-density PCB layouts and automated assembly processes.

Offers high transient voltage suppression for electronic circuits. Bi-directional diode configuration suitable for AC and DC applications. Compact surface mount package for easy PCB assembly. Provides peak pulse power dissipation of 1.5 kW for robust protection.

Operates within a temperature range of -55°C to 150°C. Features low maximum leakage current of 200 μA for energy efficiency. Complies with automotive standard AEC-Q101 ensuring reliability. Designed for fast response to voltage transients with 116.3 A maximum peak pulse current.

SMC package dimensions: 7.11 mm length x 6.22 mm width x 2.42 mm height. Test current rated at 1 mA for quality assurance. Explore more quality electronic components including TVS diodes on EnvMart for industrial, automotive, and commercial applications.
