Vishay 1-Element Bi-Directional Transient Voltage Suppressor 400 W, 2-Pin DO-214AC SMAJ33CA-E3/61

Free Delivery in India | Lowest Global Shipping Charges

Vishay 1-Element Bi-Directional Transient Voltage Suppressor 400 W, 2-Pin DO-214AC SMAJ33CA-E3/61

Name: Vishay 1-Element Bi-Directional Transient Voltage Suppressor 400 W, 2-Pin DO-214AC SMAJ33CA-E3/61
Brand: Vishay
SKU: 218045



Category Transient Voltage Suppressors Brand Vishay Condition New

Specifications

Country of Origin	India
Brand	Vishay
Height	2.09mm
Length	4.5mm
Model	SMAJ33CA-E3/61
Width	2.79mm
Mount Type	Surface
Series	TRANSZORB TVS
Maximum Operating Temperature	150°C
Package Type	DO-214AC (SMA)
Minimum Operating Temperature	-55°C
Pin Count	2
Number of Elements per Chip	1
Clamping Voltage VC	53.3V
Automotive Standard	AEC-Q101
Diode Configuration	Single
Direction Type	Bi-Directional
Minimum Breakdown Voltage Vbr	36.7V
Maximum Reverse Stand-off Voltage Vwm	33V
Peak Pulse Power Dissipation Pppm	400W
Test Current It	1mA
Maximum Peak Pulse Current Ippm	7.5A
Maximum Reverse Leakage Current	1μA

Key Features

Bi-directional diode configuration protects circuits from voltage transients in both directions.
Mount type is surface mount with a DO-214AC (SMA) package for space-efficient PCB integration.
Minimum breakdown voltage of 36.7 V ensures effective clamping during transient events.
Features a maximum reverse stand-off voltage of 33 V and clamping voltage of 53.3 V for robust transient suppression.
Operates reliably across a wide temperature range from -55°C to 150°C with automotive AEC-Q101 certification.
Offers a peak pulse current of 7.5 A and low leakage current of 1 μA for efficient protection.

Product Description

Vishay SMAJ33CA-E3/61 is a 1-element bi-directional transient voltage suppressor designed to protect sensitive electronic circuits from damaging voltage spikes and surges. Providing a peak pulse power dissipation of 400 W, this device operates efficiently within the specified voltage ratings to clamp high transient voltages effectively.

The device utilizes a single diode configuration arranged bi-directionally, allowing protection from transient voltages in both positive and negative polarities. Its surface mount DO-214AC (SMA) package enables compact mounting on printed circuit boards, reducing space without sacrificing protective capability.

This transient voltage suppressor features a minimum breakdown voltage (Vbr) of 36.7 V and a maximum reverse stand-off voltage (Vwm) of 33 V, ensuring reliable operation under normal voltage conditions while activating promptly under surge events. The device clamps transient voltages to a maximum of 53.3 V, thus protecting downstream components from high voltage stress.

Its wide operating temperature range from -55°C to 150°C suits a broad spectrum of industrial and automotive applications. The unit also meets the rigorous AEC-Q101 automotive standard, confirming its reliability and suitability for automotive electronics.

Bi-directional protection against voltage surges. Compact surface mount DO-214AC (SMA) package. Peak pulse power dissipation rating of 400 W. Low reverse leakage current minimizes power loss. Compliance with automotive AEC-Q101 standard.

Ideal for protecting sensitive electronics in industrial, automotive, and consumer devices. Robust design enables performance in harsh environmental conditions.

This robust transient voltage suppressor is widely used in electronic circuits requiring high reliability protection against electrostatic discharge (ESD) and surge events. Typical applications include power supply lines, signal lines, and automotive electronic assemblies. The combination of high power capability and compact footprint makes the Vishay SMAJ33CA-E3/61 ideal for modern electronics design challenges.
