Vishay 1-Element Bi-Directional Transient Voltage Suppressor 600W Surface Mount DO-214AA Package SMBJ15CA-E3/52
Specifications
| Country of Origin | India |
|---|---|
| Brand | Vishay |
| Height | 2.24mm |
| Length | 4.57mm |
| Model | SMBJ15CA-E3/52 |
| Width | 3.94mm |
| Mount Type | Surface |
| Series | TRANSZORB TVS |
| Maximum Operating Temperature | 150°C |
| Package Type | DO-214AA (SMB) |
| Minimum Operating Temperature | -55°C |
| Pin Count | 2 |
| Number of Elements per Chip | 1 |
| Clamping Voltage VC | 24.4V |
| Automotive Standard | AEC-Q101 |
| Diode Configuration | Single |
| Direction Type | Bi-Directional |
| Minimum Breakdown Voltage Vbr | 16.7V |
| Maximum Reverse Stand-off Voltage Vwm | 15V |
| Peak Pulse Power Dissipation Pppm | 600W |
| Test Current It | 1mA |
| Maximum Peak Pulse Current Ippm | 24.6A |
| Maximum Reverse Leakage Current | 1μA |
| TVS Diode Bi-Directional SMBJ15CA-E3/52 24.4V, 600W, DO-214AA 2-PinBrand | Vishay |
Key Features
- Single diode configuration for transient voltage suppression.
- Bi-directional voltage suppression for enhanced protection.
- Maximum reverse stand-off voltage of 15 V ensuring stable operation.
- Excellent clamping voltage at 24.4 V for effective transient protection.
- Wide operating temperature range from -55°C to 150°C.
- Low leakage current of 1 μA ensuring minimal power loss.
- Packaged in low-profile DO-214AA (SMB) surface mount package.
- Peak pulse current rating of 24.6 A for high surge tolerance.
Product Description
Vishay SMBJ15CA-E3/52 is a high-performance 1-element bi-directional transient voltage suppressor (TVS) designed for surface mount applications. It features a robust 600 W peak pulse power rating housed in a compact DO-214AA (SMB) package, making it ideal for protecting sensitive electronic components from voltage transients caused by electrostatic discharge, inductive load switching, or lightning surges.
This TVS diode offers bi-directional protection with a minimum breakdown voltage of 16.7 V and maximum reverse stand-off voltage of 15 V, ensuring that it triggers effectively to clamp voltages at a maximum of 24.4 V. The device maintains stable operation over a wide temperature range from -55°C to 150°C, making it suitable for automotive and industrial environments.
With a peak pulse current of 24.6 A and extremely low reverse leakage current of only 1 μA, the SMBJ15CA-E3/52 provides reliable protection without degrading circuit performance. Its low profile and surface mount DO-214AA package facilitate easy PCB assembly and compact device layouts.
The product meets the AEC-Q101 automotive reliability standard, guaranteeing suitability for automotive systems requiring rigorous quality assurance. Single diode for transient voltage suppression. Bi-directional protection capability.
600 W peak pulse power dissipation. Surface mount DO-214AA (SMB) package. Wide operating temperature range from -55°C to 150°C. Low leakage current for energy efficiency. Automotive-grade AEC-Q101 certified. Compact and durable design.
Ideal for industrial, automotive, and electronic device protection. Reliable transient voltage clamping performance.
Vishay's SMBJ15CA-E3/52 transient voltage suppressor is an essential component for industrial manufacturing, automotive electronics, power supplies, and various electronics requiring robust ESD protection and voltage transient mitigation. Explore more Vishay TVS diode selections and related semiconductors at EnvMart for your design and production needs.
