Broadcom DC Input Optocoupler, Through Hole Mount, 8-Pin PDIP Package 6N138-000E

Free Delivery in India | Lowest Global Shipping Charges

Broadcom DC Input Optocoupler, Through Hole Mount, 8-Pin PDIP Package 6N138-000E

Name: Broadcom DC Input Optocoupler, Through Hole Mount, 8-Pin PDIP Package 6N138-000E
Brand: Broadcom
SKU: 341751
Price: 20.22 USD
Availability: InStock



Category Electronic Components, Power & Connectors Brand Broadcom Condition New

Specifications

Country of Origin	India
Brand	Broadcom
Model	6N138-000E
Packaging	Tape & Reel
Mount Type	Through Hole
Series	6N138
Maximum Operating Temperature	100°C
Package Type	PDIP
Minimum Operating Temperature	-55°C
Maximum input current	20mA
Number Of Channels	1
Maximum Forward Voltage	1.7V
Number of Pins	8
Input Current Type	DC
Maximum Current Transfer Ratio	2600%
Minimum Current Transfer Ratio	300%

Key Features

Features a maximum forward voltage of 1.7V for efficient LED input operation.
Supports a maximum input current of 20mA with DC input power type.
Single-channel optocoupler with an 8-pin PDIP package for through-hole mounting.
Ensures high isolation voltage up to 3.75kVrms for excellent signal separation.
Operates reliably over a temperature range of -55°C to 100°C.
Offers a minimum current transfer ratio of 300% and maximum of 2600% to accommodate various signal levels.
Complies with UL 1577, CSA, and IEC/EN/DIN EN 60747-5-5 standards for safety and quality.
Suitable for logic isolation, low input current line reception, and signal line status indication.

Product Description

Broadcom 6N138-000E is a DC input optocoupler with a through-hole 8-pin PDIP package designed to provide optical isolation between input and output circuits. This device features a Darlington transistor output stage that offers high current transfer ratio with low input current requirements.

With a maximum forward voltage of 1.7V and maximum input current of 20mA, it supports efficient LED input operation. The single input channel with 8 pins is packaged in the PDIP form factor, suitable for through-hole mounting on printed circuit boards.

Broadcom's 6N138-000E optocoupler provides a high isolation voltage of 3.75kVrms, making it ideal for protecting sensitive circuits from high voltage and noisy environments. It is rated to operate over a wide temperature range from -55 degrees Celsius to 100 degrees Celsius, ensuring stable performance in industrial, commercial, and instrumentation applications.

The device offers a minimum current transfer ratio of 300% and a maximum ratio of 2600%, enabling reliable signal transmission with various input currents. It meets stringent industry safety and quality standards including UL 1577, CSA Component Acceptance Notice 5, and IEC/EN/DIN EN 60747-5-5.

Typical applications include ground isolation for logic families, low input current line receivers, EIA RS-232C line receivers, telephone ring detectors, and line voltage status indicators with low power dissipation.

Maximum forward voltage: 1.7V for LED input efficiency. Maximum input current: 20mA DC for low power operation. Isolation voltage: 3.75kVrms for robust electrical separation. Operating temperature range: -55°C to 100°C for industrial use.

Single channel, 8-pin PDIP through-hole package. Current transfer ratio: 300% minimum to 2600% maximum. Complies with UL, CSA, and IEC safety standards. Packaging: Tape and reel for automated assembly.

Broadcom optocouplers are widely used in electronics, instrumentation, industrial automation, communication equipment, and embedded systems for isolating signals and protecting low-voltage digital and analog circuitry from high-voltage spikes and noise.

Explore more electronic components and optocouplers from Broadcom available at EnvMart for your design and production needs.
