onsemi 1.27 V 500 mW Surface Mount Zener Diode Single Element 2-Pin SOD-123 MMSZ27T1G

onsemi MMSZ27T1G is a high-quality Zener diode specially designed for voltage regulation in electronic circuits. Operating at a nominal Zener voltage of 27 volts with a power dissipation of 500 mW, this diode is packaged in a compact SOD-123 surface mount case with 2 pins, making it ideal for space-constrained PCB layouts.

The diode configuration is a single element, providing reliable voltage regulation with a tolerance of ±5%. It ensures steady operation under varying electrical conditions with a low maximum Zener impedance of 80 ohms and a test current of 2 mA.

Its operating temperature range from -55°C to 150°C allows it to perform in harsh industrial environments such as manufacturing equipment, power supplies, and communication systems. With a maximum reverse leakage current of just 50 nA, it provides minimal current bleed, critical for sensitive electronic applications.

This RoHS-compliant component meets environmental regulations, ensuring no hazardous substances are present. The diode is suitable for use in industrial, laboratory, and commercial electronics applications requiring precise voltage regulation.

Key physical dimensions include a length of 3.68 mm and a height of 1.35 mm, allowing compact and efficient PCB mounting. Its surface mount nature supports modern automated assembly processes enhancing production efficiency.

This diode features a single element configuration designed for voltage regulation applications. The maximum power dissipation rating is 500 milliwatts, suitable for low power electronic circuits. Mount type is surface mount with a compact SOD-123 package measuring 3.68 mm length and 1.35 mm height.

Offers a nominal Zener voltage of 27 volts with a 5 percent tolerance for precise voltage regulation. Maximum operating temperature ranges from -55°C to 150°C, making it suitable for various temperature conditions. Maximum reverse leakage current is low at 50 nanoamperes, ensuring minimal leakage in circuits.

The maximum Zener impedance is 80 ohms, supporting stable voltage regulation. This diode complies with RoHS standards, ensuring environmental safety. Explore the full range of onsemi Zener Diodes and related Semiconductor components at EnvMart for reliable industrial and electronic design solutions.
