Texas Instruments Operational Amplifier 100 kHz 14-Pin SOIC 15.5V LMC6064IM/NOPB
Specifications
| Country of Origin | India |
|---|---|
| Brand | Texas Instruments |
| Height | 1.45mm |
| Length | 8.64mm |
| Model | LMC6064IM/NOPB |
| Width | 3.91mm |
| Mount Type | Surface |
| Series | LMC60644 |
| Output Current | 13mA |
| Maximum Operating Temperature | 85°C |
| Package Type | SOIC |
| Minimum Operating Temperature | -40°C |
| Number Of Channels | 4 |
| Pin Count | 14 |
| Maximum Supply Voltage | 15.5V |
| Minimum Supply Voltage | 5V |
| GBP - Gain Bandwidth Product | 100kHz |
| Input Bias Current | 4 pA |
| Slew Rate | 0.04V/μs |
| Input Offset Current | 2 pA |
| LMC6064IM National Semiconductor, Op AmpBrand | National Semiconductor |
Key Features
- Offers low input bias current of 4 pA for precision applications.
- Operates over a wide temperature range from -40°C to 85°C.
- Features a slew rate of 0.04 V/μs ensuring stable signal amplification.
- Includes four channels with a 14-pin configuration suitable for compact circuit designs.
- Compact dimensions with a height of 1.45 mm, length of 8.64 mm, and width of 3.91 mm.
- Maximum output current of 13 mA supports diverse output load requirements.
- Compatible with 5 V minimum to 15.5 V maximum supply voltage range.
Product Description
Texas Instruments LMC6064IM/NOPB operational amplifier is a CMOS device designed for precision and reliable amplification in industrial, electronic, and laboratory applications. It features a gain bandwidth product of 100 kHz, suited for moderate-frequency analog signal processing.
The device supports four independent amplifier channels housed in a 14-pin SOIC surface mount package, facilitating easy integration into PCB layouts requiring compact solutions.
Operating voltage ranges from a minimum of 5 V to a maximum of 15.5 V, supporting standard electronic systems. It includes protection and operational stability across a temperature range of -40°C to 85°C ensuring use in varied environmental conditions.
This operational amplifier provides a low input bias current of 4 pA and an input offset voltage of approximately 800 μV, allowing for precise signal conversion. The slew rate of 0.04 V/μs guarantees stable signal transitions without distortion.
Physical dimensions are optimized with a length of 8.64 mm, width of 3.91 mm, and height of 1.45 mm to meet size constraints in modern electronics. The maximum output current rating of 13 mA is adequate for driving typical analog circuitry.
Applications include electronic instrumentation, signal conditioning, industrial control systems, and analog processing in automotive and laboratory environments. Offers low input bias current of 4 pA for precision applications.
Operates over a wide temperature range from -40°C to 85°C. Features a slew rate of 0.04 V/μs ensuring stable signal amplification. Includes four channels with a 14-pin configuration suitable for compact circuit designs. Compact dimensions with a height of 1.45 mm, length of 8.64 mm, and width of 3.91 mm.
Maximum output current of 13 mA supports diverse output load requirements. Compatible with 5 V minimum to 15.5 V maximum supply voltage range. Series designation: LMC60644, part of the CMOS operational amplifier family. Browse the Electronics & Electricals category on EnvMart for more Operational Amplifiers and semiconductor components from leading brands like Texas Instruments.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The gain bandwidth product of this operational amplifier is 100 kHz, making it suitable for moderate-frequency analog signal processing.
It operates over a wide temperature range from -40°C to 85°C, ensuring functionality in varied environmental conditions.
The maximum output current is rated at 13 mA, which supports diverse output load requirements.
This operational amplifier includes four independent channels, allowing for multiple signal processing tasks.
The dimensions are optimized with a length of 8.64 mm, width of 3.91 mm, and height of 1.45 mm.
The input bias current is low at 4 pA, which is beneficial for precision applications.
It is compatible with a supply voltage range from 5 V to 15.5 V, supporting standard electronic systems.
The slew rate is 0.04 V/μs, ensuring stable signal transitions without distortion.
It comes in a 14-pin SOIC surface mount package, facilitating easy integration into PCB layouts.
The input offset voltage is approximately 800 μV, allowing for precise signal conversion.
It is suitable for applications in electronic instrumentation, signal conditioning, industrial control systems, and analog processing in automotive and laboratory environments.
The country of origin for the LMC6064IM/NOPB is India.
