Texas Instruments Operational Amplifier 50 kHz 14-Pin SOIC 15.5V LMC6464AIM/NOPB
Specifications
| Country of Origin | India |
|---|---|
| Brand | Texas Instruments |
| Height | 1.45mm |
| Length | 8.64mm |
| Model | LMC6464AIM/NOPB |
| Width | 3.91mm |
| Mount Type | Surface |
| Series | LMC6464 |
| Output Current | 19mA |
| Maximum Operating Temperature | 85°C |
| Package Type | SOIC |
| Minimum Operating Temperature | -40°C |
| Number Of Channels | 4 |
| Pin Count | 14 |
| Maximum Supply Voltage | 15.5V |
| Minimum Supply Voltage | 5V |
| GBP - Gain Bandwidth Product | 50kHz |
| Input Bias Current | 10 pA |
| Vos - Input Offset Voltage | 1.2 mV |
| Slew Rate | 0.03V/μs |
| Input Offset Current | 5 pA |
Key Features
- Operates with supply voltage from 5V to 15.5V.
- CMOS technology ensures low input bias current of 10 picoamperes.
- Slew rate is 0.03 V/μs enabling precise signal amplification.
- Input offset voltage is low at 1.2 mV for accuracy.
- Compact dimensions of 8.64 mm length, 3.91 mm width, and 1.45 mm height.
- Supports operating temperature range from -40 °C to 85 °C for industrial use.
- Maximum output current is 19 mA suitable for various applications.
- Includes 5 picoamperes input offset current minimizing error.
Product Description
Texas Instruments LMC6464AIM/NOPB is a high-performance operational amplifier designed for surface-mount applications in a 14-pin SOIC package. It features CMOS technology ensuring ultra-low input bias current and low offset voltage, which makes it suitable for precision amplification tasks in industrial electronics.
With a gain bandwidth of 50 kHz and a slew rate of 0.03 V/μs, the amplifier supports stable and accurate signal processing. Its four independent channels offer versatile integration options in complex circuits.
The device operates within a supply voltage range of 5V to 15.5V and withstands temperatures from -40 °C to 85 °C, making it suitable for demanding environments including industrial automation, laboratory instrumentation, and embedded systems.
Physical dimensions of length 8.64 mm, width 3.91 mm, and height 1.45 mm support compact PCB layouts. The output current capability up to 19 mA ensures compatibility with various downstream loads.
Operates over wide voltage and temperature ranges for robustness. Four independent channels provide design flexibility. Low input bias and offset currents enhance signal fidelity. Compact SOIC package supports dense circuit board designs.
Suitable for industrial, laboratory, and electronic component applications. CMOS technology ensures low power consumption. Ideal for precision analog signal processing and amplification.
This Texas Instruments operational amplifier is an essential component for professionals in electronics design, manufacturing, HVAC control systems, instrumentation, and automation industries requiring reliable performance and long service life.
Explore more Operational Amplifiers and semiconductor components at EnvMart for your technical and industrial project needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The gain bandwidth product of this operational amplifier is 50 kHz, allowing for stable and accurate signal processing.
The maximum supply voltage for the LMC6464AIM/NOPB is 15.5V, making it suitable for a variety of applications requiring different voltage levels.
This operational amplifier features an input bias current of 10 picoamperes, which contributes to its precision in amplification tasks.
The operational amplifier operates within a temperature range of -40 °C to 85 °C, making it suitable for industrial applications.
This model has four independent channels, providing flexibility for integration in complex circuits.
The dimensions of the LMC6464AIM/NOPB are 8.64 mm in length, 3.91 mm in width, and 1.45 mm in height, supporting compact PCB layouts.
The slew rate of this operational amplifier is 0.03 V/μs, enabling precise signal amplification.
The input offset voltage for the LMC6464AIM/NOPB is low at 1.2 mV, enhancing its accuracy in signal processing.
This operational amplifier can provide a maximum output current of 19 mA, suitable for various downstream loads.
The LMC6464AIM/NOPB is designed for surface mount applications, which is typical for modern electronic designs.
This operational amplifier utilizes CMOS technology, ensuring low power consumption and low input bias current.
The minimum supply voltage for the LMC6464AIM/NOPB is 5V, allowing it to operate effectively in a variety of electronic circuits.
