Texas Instruments RS-485 Differential Non-Inverting Line Transceiver, 8-Pin SOIC, 4.75V-5.25V Supply SN75176AD
Specifications
| Country of Origin | Mexico |
|---|---|
| Brand | Texas Instruments |
| Height | 1.75mm |
| Length | 5mm |
| Model | SN75176AD |
| Width | 3.98mm |
| Mount Type | Surface |
| Output type | Differential |
| Series | SN75176A |
| Input Type | Differential |
| Maximum Operating Temperature | 70°C |
| Package Type | SOIC |
| Minimum Operating Temperature | 0°C |
| Polarity | Non-Inverting |
| IC Type | Line Transceiver IC |
| Number Of Channels | 1 |
| Pin Count | 8 |
| Maximum Supply Voltage | 5.25V |
| Logic Family | SN75 |
| Logic Function | Bus Transceiver |
| Minimum Supply Voltage | 4.75V |
| Maximum High Level Output Current | -60mA |
| Maximum Propagation Delay Time @ CL | 35ns |
| Supply Current | 50mA |
| Maximum Low Level Output Current | 60mA |
Key Features
- Supports differential input and output signals for robust communication.
- Operates with a supply current of 50mA for efficient power use.
- Maintains operation temperatures from 0°C to 70°C.
- Has a maximum propagation delay time of 35ns for fast data transmission.
- Designed with a 1-channel line transceiver IC configuration.
- Compact SOIC package with 8 pins and small form factor dimensions.
- Non-inverting polarity ensures signal integrity in bus transceiver applications.
- Manufactured in Mexico and compliant with standard semiconductor quality measures.
Product Description
Texas Instruments SN75176AD is a high-speed RS-485 line transceiver designed to support differential, non-inverting signals with a robust bus transceiver logic function. Packaged in an 8-pin SOIC surface mount package, it operates within a supply voltage range of 4.75V to 5.25V, ensuring compatibility with a wide range of industrial and commercial applications.
This line transceiver features a single channel IC type with differential input and output, allowing for efficient two-way communication on network buses. Its maximum propagation delay time of 35ns at load capacitance ensures reliable high-speed data transfer, suitable for RS-485 protocols and differential line driver applications.
The device supports a supply current of 50mA and is designed to operate in ambient temperatures from 0°C up to 70°C, making it durable for various environmental conditions. The compact 5mm length, 3.98mm width, and 1.75mm height dimensions, along with the SOIC surface mount package, facilitate space-saving PCB layouts.
The SN75176AD maintains non-inverting polarity, critical for signal clarity in bus transceiver roles, with output currents rated at -60mA (high) and 60mA (low). It does not have specific automotive standards approval but is manufactured under Texas Instruments' high-quality semiconductor processes in Mexico.
Supports data rates exceeding 10 Mbit/s for high-speed data communication. Ideal for industrial, electronic components, and power and connectors applications. Compatible with RS-485 line drivers and receivers standards. Surface mount SOIC package allows for efficient automated assembly.
Extensively used in electronic interface circuits and communication IC applications.
This product is categorized under Industrial Electronics and Semiconductor devices, offering a reliable solution for line communication and control functions across automotive, manufacturing, and communication equipment sectors. Explore more Texas Instruments semiconductors and line transceivers in EnvMart's catalog for comprehensive industrial solutions.
Explore more products in our Line Transceiver IC category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The SN75176AD operates within a supply voltage range of 4.75V to 5.25V.
It has a maximum propagation delay time of 35ns, allowing for fast data transmission.
This model has dimensions of 5mm in length, 3.98mm in width, and 1.75mm in height.
The SN75176AD operates in ambient temperatures from 0°C to 70°C.
It provides a differential output, which is essential for robust communication.
This model is designed as a single channel line transceiver IC.
The device supports a supply current of 50mA during operation.
The maximum high level output current is rated at -60mA, while the maximum low level output current is 60mA.
It comes in a compact SOIC surface mount package with 8 pins.
This model functions as a bus transceiver, supporting differential signaling.
While it does not have specific automotive standards approval, it is manufactured under standard semiconductor quality measures.
It is ideal for industrial, electronic components, and communication IC applications, particularly in RS-485 protocols.
