Broadcom 1.9 V Red LED 5 mm (T-1 3/4) Through Hole HLMP-E HLMP-EG08-YZ000

Free Delivery in India | Lowest Global Shipping Charges

Broadcom 1.9 V Red LED 5 mm (T-1 3/4) Through Hole HLMP-E HLMP-EG08-YZ000

Name: Broadcom 1.9 V Red LED 5 mm (T-1 3/4) Through Hole HLMP-E HLMP-EG08-YZ000
Brand: Broadcom
SKU: 336357
Price: 20.22 USD
Availability: InStock



Category Electronic Components, Power & Connectors Brand Broadcom Condition New

Specifications

Country of Origin	India
Brand	Broadcom
Model	HLMP-EG08-YZ000
Mount Type	Through Hole
Series	HLMP-E
Maximum forward current	50mA
Viewing angle	8 °
Package Type	5 mm (T-1 3/4)
Standards/Approvals	RoHS Compliant
LED Colour	Red
Dominant Wavelength	626nm
Forward Voltage	1.9V
Number of Pins	2
LED Luminosity	12.6 cd
Lens Dimensions	5 x 8.71 mm
Lens Shape	Round
Lens Finish	Non-Diffused
LED Luminous Flux	500 mLm

Key Features

The LED emits bright red light with a dominant wavelength of 626 nm.
It features a 5 mm (T-1 3/4) round, non-diffused clear lens.
The LED supports a maximum forward current of 50mA and has 2 pins for through-hole mounting.
Offers a narrow viewing angle of 8 degrees for focused light emission.
Its luminous intensity is 12.6 cd with a luminous flux of 500 mLm.
Constructed from optical grade epoxy with high temperature and moisture resistance.
It complies with RoHS regulations ensuring environmentally friendly components.
Suitable for applications needing long-term light stability like traffic signals and outdoor signage.

Product Description

Broadcom HLMP-EG08-YZ000 is a 1.9 V red LED with a 5 mm (T-1 3/4) package designed for through-hole mounting. This LED belongs to the HLMP-E series known for extra high brightness and precision optical performance utilizing AllnGaP technology.

This high-luminosity LED emits red light at a dominant wavelength of 626 nm with a luminous intensity of 12.6 cd and luminous flux of 500 mLm, ensuring excellent visibility even in bright outdoor environments. The LED’s narrow 8-degree viewing angle produces a precise, well-defined spatial radiation pattern for targeted illumination.

The round, non-diffused clear lens measures 5 x 8.71 mm and is made from optical grade epoxy, providing superior resistance against high temperature and moisture, making it ideal for demanding industrial and outdoor applications such as traffic management, solar power signs, and commercial outdoor advertising.

Compliant with RoHS directives, the HLMP-EG08-YZ000 ensures environmentally safe usage. Its robust design includes ultraviolet inhibitors to reduce aging effects from direct sunlight exposure, maintaining long-term stable light output.

This LED is engineered for industrial, electronic component manufacturing, and outdoor signaling use cases, offering dependable performance and precision illumination. The through-hole mount type with 2 pins supports easy integration into circuit boards.

The LED emits bright red light at 626 nm wavelength. Superior high-temperature and moisture resistance. Compact 5 mm T-1 3/4 package with clear, round lens. 8° narrow viewing angle for focused light. Maximum forward current of 50 mA.

Complies with RoHS environmental standards. Durable epoxy material with UV inhibitors. Suitable for outdoor signaling and electronic display applications. Designed for industrial and commercial lighting projects. Explore more high-quality LEDs and electronic components in the Electronics Components category at EnvMart for your industrial and commercial requirements.
