Broadcom 1.9 V Red LED 5 mm (T-1 3/4) Through Hole HLMP-EG08-YZ000

Free Delivery in India | Lowest Global Shipping Charges

Broadcom 1.9 V Red LED 5 mm (T-1 3/4) Through Hole HLMP-EG08-YZ000

Name: Broadcom 1.9 V Red LED 5 mm (T-1 3/4) Through Hole HLMP-EG08-YZ000
Brand: Broadcom
SKU: 336344
Price: 20.22 USD
Availability: InStock



Category Electronic Components, Power & Connectors Brand Broadcom Condition New

Specifications

Country of Origin	India
Brand	Broadcom
Model	HLMP-EG08-YZ000
Mount Type	Through Hole
Series	HLMP-E
Maximum forward current	50mA
Viewing angle	8 °
Package Type	5 mm (T-1 3/4)
Standards/Approvals	RoHS Compliant
Pay online using	Or choose to pay later via bank transfer
RS Stock No.	496-6178P Brand: [Broadcom](https://in.rsdelivers.com/brands/broadcom)Manufacturers Part No.: HLMP-EG08-YZ000
LED Colour	Red
Dominant Wavelength	626nm
Forward Voltage	1.9V
Number of Pins	2
LED Luminosity	12.6 cd
Lens Dimensions	5 x 8.71 mm
Lens Shape	Round
Lens Finish	Non-Diffused
LED Luminous Flux	500 mLm

Key Features

This red LED has a forward voltage of 1.9 volts and maximum forward current of 50 mA.
It features a 5 mm T-1 3/4 package with through-hole mounting type.
The LED has a narrow viewing angle of 8 degrees for focused illumination.
Lens dimensions are 5 x 8.71 mm with a round, non-diffused clear lens.
LED luminosity rating is 12.6 cd and luminous flux is 500 mLm.
Constructed with optical-grade epoxy providing high temperature and moisture resistance.
Complies with RoHS standards for environmental safety.
Designed for outdoor applications such as traffic management and solar powered signs.

Product Description

Broadcom HLMP-EG08-YZ000 is a high-performance 1.9 V red LED in a 5 mm T-1 3/4 through hole package, engineered for industrial and commercial outdoor use. It offers superior luminous output with a focused 8° viewing angle and a bright luminosity of 12.6 cd, making it ideal for applications demanding high visibility.

This LED features a forward current rating of 50 mA and a forward voltage of 1.9 V. The lens is made from optical-grade epoxy, providing robust resistance to high temperature and moisture, suitable for rugged outdoor environments. The non-diffused, clear round lens delivers precise light output without distortion.

The HLMP-EG08-YZ000 belongs to the HLMP-E series of Avago Technologies LEDs, known for their advanced AllnGaP technology which ensures stable light output over extended periods. This feature makes it reliable in traffic management systems, commercial outdoor advertising, and solar-powered signs where sunlight readability is critical.

These LEDs include UV-A and UV-B inhibitors to protect against long-term sunlight exposure, enhancing lifespan and performance reliability. The product is RoHS compliant, ensuring it meets strict environmental safety standards.

High brightness red LED with narrow 8° viewing angle for focused light emission. Robust construction with epoxy lens resistant to moisture and temperature. Forward current of 50 mA and forward voltage of 1.9 V suitable for low power circuits.

Clear round non-diffused lens for precise light distribution. Designed for industrial, commercial, traffic, and solar outdoor applications. RoHS compliant and environmentally safe LED product. Advanced AllnGaP technology for stable and consistent light output.

Broadcom LEDs like the HLMP-EG08-YZ000 are well-suited for use in electronic components assemblies within the electronics, industrial, and signaling industries. Explore our category for more LED and optoelectronic devices to find the optimal solution for your project needs.
