Winslow 2.54 mm Pitch Vertical 24 Way Through Hole Turned Pin Open Frame DIL Socket 5A W30524/3TTRC
Specifications
| Country of Origin | India |
|---|---|
| Brand | Winslow |
| Orientation | Vertical |
| Current | 5A |
| Temperature range | -55°C to +150 °C |
| Frame Type | Open Frame |
| Length | 30.4mm |
| Model | W30524/3TTRC |
| Depth | 10.14mm |
| Width | 4.6mm |
| Mount Type | Through Hole |
| Housing Material | Polybutylene Terephthalate |
| Contact Material | Beryllium Copper Alloy |
| Termination Type | Solder |
| Maximum Operating Temperature | 150°C |
| Pitch | 2.54mm |
| Contact Plating | Tin |
| Number of Contacts | 24 |
| Pin Type | Turned |
| Row Width | 7.62mm |
Key Features
- The socket features 24 contacts arranged with a 2.54 mm pitch and 7.62 mm row width.
- Constructed with beryllium copper alloy contacts plated with tin for excellent conductivity and corrosion resistance.
- Designed for a current rating of 5A and maximum operating temperature of 150°C.
- The housing is made of durable polybutylene terephthalate material ensuring insulation and mechanical stability.
- Vertical orientation and solder termination type suit PCB mounting applications.
- Compact dimensions with a length of 30.4 mm, width of 4.6 mm, and depth of 10.14 mm.
- Low profile, high-quality turned pin configuration provides reliable and consistent contact.
- Operates within a temperature range from -55°C to +150°C for versatility in demanding environments.
Product Description
Winslow W30524/3TTRC is a high-quality 24-way DIL socket designed for vertical, through hole mounting applications on printed circuit boards. Featuring a precise 2.54 mm pitch and 7.62 mm row width, this socket is engineered for reliable electronic connections with its low profile open frame design.
The turned pin contacts are made of beryllium copper alloy plated with tin, which ensures excellent conductivity, mechanical strength, and resistance to corrosion. With a current rating of 5 amperes and a maximum operating temperature of 150°C, it provides reliable performance even in demanding industrial and laboratory environments.
The socket housing consists of polybutylene terephthalate, providing durability, insulation, and thermal stability. Its solder termination type and vertical orientation ensure secure and easy PCB mounting during assembly processes.
Compact in size with dimensions of 30.4 mm in length, 4.6 mm in width, and 10.14 mm in depth, this socket is well suited for various electronics applications including industrial controls, measurement instrumentation, and prototyping of electronic circuits.
The operating temperature range from -55°C to +150°C allows this socket to be used across a wide variety of temperature environments typical in manufacturing, HVAC systems, and electronic testing laboratories.
The socket has 24 contacts with a pitch of 2.54 mm and a row width of 7.62 mm. Features an open frame, low profile design optimized for through hole mounting. Contacts are turned pins plated with tin to enhance durability and electrical performance.
Rated for a maximum current of 5 A and solder termination for reliable PCB connection. Constructed with polybutylene terephthalate housing for insulation and strength. Suitable for industrial, laboratory, and electronics manufacturing applications.
Explore the wide range of DIL Sockets available at EnvMart for your electronic component needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The Winslow W30524/3TTRC DIL socket has a current rating of 5A.
This socket operates within a temperature range of -55°C to +150°C.
The socket has dimensions of 30.4 mm in length, 4.6 mm in width, and 10.14 mm in depth.
It supports through hole mounting, suitable for printed circuit boards.
The housing is made of polybutylene terephthalate, providing insulation and mechanical stability.
This model features 24 contacts arranged with a 2.54 mm pitch and a 7.62 mm row width.
It uses turned pin contacts made of beryllium copper alloy plated with tin for enhanced conductivity.
The termination type is solder, ensuring a reliable connection during PCB assembly.
This DIL socket is suitable for various applications including industrial controls, measurement instrumentation, and electronic circuit prototyping.
The Winslow W30524/3TTRC is designed for vertical orientation.
The maximum operating temperature for this socket is 150°C.
The contacts are arranged with a pitch of 2.54 mm.
