STMicroelectronics 150 V 30 A Through Hole Schottky Diode 3-Pin TO-247 STPS30150CW
Specifications
| Country of Origin | India |
|---|---|
| Brand | STMicroelectronics |
| Height | 20.15mm |
| Length | 15.75mm |
| Model | STPS30150CW |
| Width | 5.15mm |
| Mount Type | Through Hole |
| Series | STPS30150C |
| Maximum Operating Temperature | 175°C |
| Package Type | TO-247 |
| Minimum Operating Temperature | -65°C |
| Standards/Approvals | Epoxy meets UL94, V0 |
| Pin Count | 3 |
| Maximum Continuous Forward Current If | 30A |
| Peak Reverse Repetitive Voltage Vrrm | 150V |
| Diode Configuration | Common Cathode |
| Rectifier Type | Schottky |
| Peak Reverse Current Ir | 6.5μA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 220A |
| Maximum Forward Voltage Vf | 0.75V |
| STMicroelectronics 100V 30A, Dual Schottky Diode, 3-Pin TO-247 STPS30H100CWBrand | STMicroelectronics |
Key Features
- Maximum continuous forward current of 30 amperes supports high current applications.
- Peak reverse repetitive voltage rating of 150 volts ensures robust voltage blocking capability.
- Low forward voltage of 0.75 volts reduces power loss and heat generation.
- Wide operating temperature range from -65°C to 175°C suits harsh industrial environments.
- Compact TO-247 package with length 15.75 mm, width 5.15 mm, and height 20.15 mm enables easy through-hole mounting.
- Schottky diode configuration with common cathode and 3 pins offers fast switching performance.
- Peak non-repetitive forward surge current rating of 220 amperes allows short-duration overload protection.
- Epoxy meets UL94 V0 flammability standard, ensuring safety and durability.
Product Description
STMicroelectronics STPS30150CW is a Schottky barrier diode rated for 150 volts peak reverse repetitive voltage and a maximum continuous forward current of 30 amperes. It comes in a reliable 3-pin TO-247 through hole mounting package featuring dimensions of 15.75 mm length, 5.15 mm width, and 20.15 mm height. This diode exhibits a low maximum forward voltage of 0.75 volts which significantly contributes to efficient power management by minimizing conduction losses and heat generation.
The diode configuration is common cathode, optimized for fast rectification and switching, and capable of handling surge currents up to 220 amperes peak non-repetitive. Operating across a wide temperature range from -65°C to 175°C, it is well suited for demanding industrial, power electronics, and automotive applications that require durable and reliable semiconductor components.
The epoxy molding used complies with UL94 V0 flammability standard, enhancing the component's safety and structural integrity. The STPS30150CW diode is ideal for power rectification, protection circuits, and other semiconductor applications in manufacturing, construction of electronic devices, HVAC controls, and more.
Maximum continuous forward current of 30 amperes supports high current applications. Peak reverse repetitive voltage rating of 150 volts ensures robust voltage blocking capability. Low forward voltage of 0.75 volts reduces power loss and heat generation.
Wide operating temperature range from -65°C to 175°C suits harsh industrial environments. Compact TO-247 package with length 15.75 mm, width 5.15 mm, and height 20.15 mm enables easy through-hole mounting. Schottky Diode configuration with common cathode and 3 pins offers fast switching performance.
Peak non-repetitive forward surge current rating of 220 amperes allows short-duration overload protection. Epoxy meets UL94 V0 flammability standard, ensuring safety and durability. Suitable for use in power conversion, rectification, and protection circuits in industrial and electronic equipment.
Explore more semiconductor diodes and power components at EnvMart for your industrial, laboratory, and commercial electronic needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum continuous forward current of this model is 30 amperes, making it suitable for high current applications.
This diode has a peak reverse repetitive voltage rating of 150 volts, ensuring robust voltage blocking capability.
The maximum forward voltage of this diode is 0.75 volts, which helps reduce power loss and heat generation during operation.
It operates across a wide temperature range from -65°C to 175°C, making it suitable for harsh industrial environments.
The diode comes in a TO-247 package with dimensions of 15.75 mm in length, 5.15 mm in width, and 20.15 mm in height.
The STPS30150CW features a common cathode configuration, which is optimized for fast rectification and switching performance.
This model has a peak non-repetitive forward surge current rating of 220 amperes, allowing for short-duration overload protection.
The epoxy used in this diode meets the UL94 V0 flammability standard, ensuring safety and durability.
This diode features a 3-pin configuration, suitable for through-hole mounting.
The STPS30150CW is a Schottky rectifier, known for its fast switching capabilities and low forward voltage.
It is suitable for power rectification, protection circuits, and other semiconductor applications in industrial and electronic equipment.
The peak reverse current for this diode is rated at 6.5μA, indicating its low leakage characteristics.
