Nexperia Schottky Diode 30 V 200 mA Surface Mount LLDS Package BAS85,115

Name: Nexperia Schottky Diode 30 V 200 mA Surface Mount LLDS Package BAS85,115
Brand: Nexperia
SKU: 331110
Price: 20.22 USD
Availability: InStock



Category Schottky Diodes & Rectifiers Brand Nexperia Condition New

Specifications

Country of Origin	China
Brand	Nexperia
Height	1.6mm
Length	3.7mm
Model	BAS85,115
Width	1.6mm
Mount Type	Surface
Series	BAS85
Maximum Operating Temperature	125°C
Package Type	LLDS
Minimum Operating Temperature	-65°C
Pin Count	2
Maximum Continuous Forward Current If	200mA
Peak Reverse Repetitive Voltage Vrrm	30V
Diode Configuration	Single
Rectifier Type	Schottky
Peak Reverse Current Ir	2.3μA
Peak Non-Repetitive Forward Surge Current Ifsm	5A
Maximum Forward Voltage Vf	800mV

Key Features

Features a maximum continuous forward current of 200 mA.
Housed in an ultra-small, low-profile LLDS package measuring 3.7 mm by 1.6 mm by 1.6 mm.
Optimized for low forward voltage drop and high junction temperature operation up to 125°C.
Exhibits very low leakage current with peak reverse current of only 2.3 µA.
Supports a peak non-repetitive surge current of 5 A, suitable for transient conditions.
Single diode configuration with two pins designed for surface mounting.
Operating temperature range from -65°C to 125°C for reliable performance in harsh environments.
Manufactured in China to industrial standards without automotive certification.

Product Description

Nexperia BAS85,115 Schottky Diode is a high-efficiency surface-mount diode with a maximum continuous forward current of 200 mA and peak reverse voltage of 30 V. This diode comes in an ultra-compact LLDS package measuring 3.7 mm length, 1.6 mm width, and 1.6 mm height, optimized for applications requiring low forward voltage drop and high junction temperature resilience up to 125°C.

The BAS85,115 diode exhibits a very low peak reverse current of 2.3 µA and supports a peak surge current of 5 A, making it ideal for transient voltage protection and fast switching in power-sensitive circuits. Its single diode configuration and two-pin layout ensure ease of integration in surface-mount PCB designs.

Operating temperature spans from -65°C to 125°C, ensuring robust performance in industrial, electronic component, power, and connector applications. Manufactured in China, this diode is suitable for discrete semiconductor uses demanding reliable Schottky barrier diode characteristics.

Maximum continuous forward current of 200 mA. Peak reverse repetitive voltage rating of 30 V. Low forward voltage of 800 mV enhancing energy efficiency. Compact LLDS surface mount package for space-constrained designs. Wide operating temperature range from -65°C to 125°C.

High surge current capability of 5 A. Negligible leakage and power switching losses.

This diode is widely used in industrial electronics, power supplies, and automotive electronic circuits requiring Schottky diode performance within a compact form factor. It enables efficient rectification and fast switching with minimal energy losses.
