onsemi 8-Bit Non-Inverting CMOS Bus Transceiver, Surface Mount SOIC 20-Pin Logic IC MC74ACT245DWG

onsemi MC74ACT245DWG is an 8-bit non-inverting CMOS bus transceiver designed to provide bidirectional data communication on buses. Packaged as a 20-pin SOIC surface mount component, this logic IC belongs to the MC74ACT series of ACT logic family devices optimized for high speed and low power consumption.

Operating at a supply voltage range of 4.5V to 5.5V, it features TTL input and CMOS output levels, ensuring compatibility with a wide range of digital circuits. With a maximum propagation delay time of 8 nanoseconds, it supports rapid data transmission for various electronic designs.

The device supports 3-state outputs facilitating bus sharing and flexible data line management in complex digital systems. It operates reliably across a broad temperature range from -40°C to 85°C which meets industrial usage requirements.

Physically, the transceiver comes in a standard SOIC package measuring 12.95mm in length and 2.45mm in height, suitable for compact PCB layouts. It is not designed for automotive standard compliance but fits many industrial, laboratory, and commercial electronic applications.

Typical industrial use includes digital bus buffering, signal line interfacing, data routing in computer motherboards, instrumentation, and communication equipment. Its robust electrical characteristics make it ideal for integration in semiconductor-based circuit designs requiring dependable bus line transceiver functionality.

Includes 8 channels with non-inverting polarization ensuring signal integrity and direction control. ACT logic family device provides low power consumption and high-speed operation. TTL input and CMOS output levels for wide compatibility with digital logic circuits.

3-state output type supports multiple device connection on shared bus lines. Temperature and voltage specifications suitable for industrial environment conditions.

The product is packaged and sold ready for insertion and integration into manufacturing workflows, improving production efficiency. The MC74ACT245DWG is widely supported with design documents and 3D models, making it a versatile choice for electronics design engineers.
