onsemi High-Speed CMOS 4 2-Input NAND Logic Gate, 14-Pin SOIC MC74HC00ADR2G

onsemi MC74HC00ADR2G is a high-speed CMOS logic IC featuring four 2-input NAND gates housed in a 14-pin SOIC surface mount package. It operates efficiently within a supply voltage range of 2 to 6 volts and provides a maximum propagation delay of 19 nanoseconds, making it suitable for fast logic applications.

The device supports input CMOS and output LSTTL compatibility, enhancing flexibility in various digital circuits. It boasts a broad operating temperature range from -55°C to 125°C, ensuring reliable performance under harsh industrial and automotive conditions.

This logic gate IC is compliant with the automotive standard AEC-Q100, confirming its suitability for automotive electronics systems. Its compact 14-pin SOIC package enables space-saving layouts on PCBs used in industrial, automotive, telecommunications, and consumer electronics applications.

With maximum high and low-level output currents of 5.2 mA, the MC74HC00ADR2G ensures adequate drive capabilities while maintaining low power consumption typical of the 74HC family.

Includes four independent 2-input NAND gates. Operates at 2 to 6 V supply voltage. High-speed switching with 19 ns maximum delay. Wide operating temperature range: -55°C to 125°C. CMOS input, LSTTL output compatibility. AEC-Q100 automotive grade quality.

Compact 14-Pin SOIC surface mount package. Low power consumption and moderate output drive current.

Ideal for industrial automation, automotive electronics control systems, digital signal processing, embedded computing, and communication hardware requiring reliable NAND logic functionality. Explore similar semiconductor ICs and Logic Gates in EnvMart for your design and manufacturing needs.
