Murata Power Solutions Through Hole Pulse Transformer 1:2.2 Turns Ratio, 234 μH Primary Inductance, 0.5Ω Primary 782485/35C

Murata Power Solutions 782485/35C Through Hole Pulse Transformer is designed for efficient signal transfer in electronic circuits featuring a 1:2.2 turns ratio, primary inductance of 234 μH, and primary resistance of 0.5Ω. It employs a through-hole mount type that provides robust mechanical stability and is compatible with widely used PCB standards.

This pulse transformer supports a current rating of up to 200mA with a low leakage inductance of 0.168 μH, which ensures minimal signal distortion and high accuracy in signal isolation. Operating temperature range between -40°C and 85°C allows it to perform reliably in a wide array of industrial and commercial environments.

The unit’s compact size - measuring 9.14mm in length, 10.46mm in width, and 6.35mm in depth - and lightweight build of 1 gram make it ideal for applications where space and weight are critical factors.

With an isolation voltage rating of 2500 Vrms, this transformer guarantees strong electrical isolation, enhancing protection in sensitive circuits such as RS-485 and RS-232 interfaces. It also meets RoHS standards, reflecting Murata's commitment to environmental and safety regulations.

The transformer is suitable for use in industrial machinery, telecommunication equipment, and electronic instrumentation where reliable pulse transmission and electrical isolation are required. It is well-suited for integration into designs requiring industry-standard pinouts and low-profile packages compatible with Analog Devices AMD2452E ICs.

Through hole mount ensures secure installation and reliable electrical connection. Maximum operating temperature of 85°C and minimum of -40°C suitable for varied environments. Leakage inductance is 0.168 μH, allowing precise signal transmission.

Compact dimensions of 9.14mm length, 10.46mm width, and 6.35mm depth for space-constrained applications. Designed for up to 200mA current to enhance performance in electronic circuits. 6-pin configuration compatible with industry standard PCB layouts.

Isolation voltage rated at 2500 Vrms for electrical safety compliance. RoHS compliant ensuring environmental safety and quality. Lightweight construction at 1 gram facilitates easy incorporation into devices. Explore the full range of Pulse Transformers available at EnvMart to find the product best suited for your high-performance electronic design requirements.
